Installing the Router
Item
Reset
Button
LEDs
LAN
Ports
Printer
Port
WAN
Port
COM
Port
Power
Inlet

System Requirements

You must have an ISP that meets the following minimum
requirements:
•
Internet access from your local telephone company or Internet
Service Provider (ISP) using a DSL modem, cable modem,
ISDN TA, or PSTN analog modem. You may also have access
over the telephone system to an analog modem at another
site.
•
A PC using a fixed IP address or dynamic IP address
assigned via DHCP, as well as a Gateway server address and
DNS server address from your service provider.
•
A computer equipped with a 10 Mbps, 100 Mbps, or
10/100 Mbps Fast Ethernet card, or a USB-to-Ethernet
converter.
6
Description
Use this button to reset the power and restore the default
factory settings.
Power, WAN and LAN port status indicators.
(See "LED Indicators" on page 1.)
Fast Ethernet ports (RJ-45). Connect devices (such as a
PC, hub or switch) on your local area network to these
ports.
Parallel port (25-pins, D-type, female). Connect the shared
printer to this port.
WAN port (RJ-45). Connect your cable modem, DSL
modem, or an Ethernet router to this port.
Serial port (9-pins, D-type, male). Connect your ISDN TA or
56K analog modem to this port.
Connect the included power adapter to this inlet.
Warning: Using the wrong type of power adapter may
cause damage.
