Summary of Contents for SMC Networks 7004VBR - annexe 2

  • Page 2 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, or for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.
  • Page 3 Note: In order to maintain compliance with the limits of a Class B digital device, SMC requires that you use a quality interface cable when connecting to this device. Changes or modifications not expressly approved by SMC could void the user’s authority to operate this equipment.
  • Page 4 EC Conformance Declaration – Class B SMC contact for these products in Europe is: SMC Networks Europe, Edificio Conata II Calle Fructuos Gelabert 6-8, 2o, 4a 08970 – Sant Joan Despi Barcelona, Spain This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022/A1 Class B, and EN 50082-1.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS 1 | SYSTEM REQUIREMENTS 2 | EQUIPMENT CHECKLIST 3 | FUNCTIONS AND FEATURES 4 | PANEL LAYOUT 5 | HARDWARE INSTALLATION 6 | NETWORK SETTINGS AND SOFTWARE INSTALLATION 6.1 | Installing TCP/IP 6.2 | Setting up TCP/IP 6.3 | Obtaining an IP Address 6.4 | Configuring a Macintosh Computer 6.5 | Verifying Your TCP/IP Connection...
  • Page 6 7.3.8| BigPond 7.4 | Advanced Setup – SYSTEM 7.4.1| Time Zone 7.4.2| Password Settings 7.4.3| Remote Management 7.5 | Advanced Setup - WAN 7.5.1| Dynamic IP 7.5.2| PPPoE 7.5.3| PPTP 7.5.4| Static IP 7.5.6| BigPond 7.6 | Advanced Setup - LAN 7.7 | Advanced Setup - NAT 7.7.1 | Virtual Server 7.7.2 | Special Applications...
  • Page 7 8 | TROUBLESHOOTING 9 | TERMINOLOGY 10 | TECHNICAL SPECIFICATIONS 11 | COMPLIANCES 12 | LEGAL INFORMATION AND CONTACTS...

  • Page 8: System Requirements

    Immediately inform your dealer in the event of any incorrect, missing or damaged parts. If possible, please retain the carton and original packing materials in case there is a need to return the product. Please register this product and upgrade the product warranty at SMC's Web site: http://www.smc.com...

  • Page 9: Functions And Features

    3 | Functions and Features Connects multiple computers to a broadband (cable or DSL) Broadband Modem and NAT Router modem, and/or Ethernet router to access the Internet. Provides a 10/100 Base-TX interface to connect to a DSL or cable 10/100 Mbps Ethernet Interface modem for broadband Internet access.

  • Page 10: Panel Layout

    4 | Panel Layout The following figure shows the front panel layout, which is followed by a table describing in detail the status and function of each LED. SMC7004VBR FLASHING Receiving power Not receiving power Good WAN No WAN Transmitting or connection detected connection detected receiving traffic...

  • Page 11: Network Settings And Software Installation

    6 | Network Settings and Software Installation Default Settings 192.168.2.1 IP Address 255.255.255.0 Subnet Mask smcadmin Administrator Password You must first verify that the TCP/IP communication protocol is properly installed and the computer is configured to get its IP address via the DHCP Server that is built-into this router. If you have not previously installed TCP/IP protocols on your client PCs, refer to the following section.

  • Page 12: Obtaining An Ip Address

    CD-ROM drive). 9. Windows may prompt you to restart the PC. If so, click the Yes button. If Windows does not prompt you to restart your computer, do so to insure your settings. Windows NT 1. From the Windows desktop click Start/Settings/Control Panel. 2.

  • Page 13: Configuring A Macintosh Computer

    6.4 | Configuring a Macintosh Computer You may find that the instructions here do not exactly match your screen. This is because these steps and screen shots were created using Mac OS 10.2. Mac OS 7.x and above are all very similar, but may not be identical to Mac OS 10.2.

  • Page 14: Configuring Your Broadband Router

    7 | Configuring Your Broadband Router Before you attempt to log into the web-based Administration, please verify the following. 1. Your browser is configured properly (see below). 2. Disable any firewall or security software that may be running. 3. Confirm that you have a good link LED where your computer is plugged into the Router. If you don’t have a link light, then try another cable until you get a good link.

  • Page 15: Setup Wizard

    7.3 | Setup Wizard 7.3.1 Time Zone After logging into the web management, click on SETUP WIZARD on the top left navigation panel. The first item is Time Zone. For accurate timing of client filtering and log events, you need to set the time zone. Select your time zone from the drop-down list.

  • Page 16: Cable Modem

    7.3.4 Cable Modem The cable modem option allows you to configure a host name and MAC Address. The Host Name is optional, but may be required by some ISPs. The default MAC address is set to the WAN’s physical interface on the Router. Use this address when registering for Internet service, and do not change it unless required by your ISP.

  • Page 17: Pppoe Xdsl

    7.3.6 PPPoE xDSL Enter the PPPoE User Name and Password assigned by your Service Provider. The Service Name is normally optional, but may be required by some service providers. Leave the Maximum Transmission Unit (MTU) at the default value unless you have a particular reason to change it. Enter a Maximum Idle Time (in minutes) to define a maximum period of time for which the Internet connection is maintained during inactivity.

  • Page 18: Pptp

    7.3.7 PPTP Point-to-Point Tunneling Protocol is a common connection method used for xDSL connections in Europe. It can be used to join different physical networks using the Internet as an intermediary. If you have been provided with the information as shown on the screen, enter the assigned IP address, subnet mask, default gateway IP address, user ID and password, and PPTP Gateway.

  • Page 19: Advanced Setup - System

    7.4 | Advanced Setup – SYSTEM 7.4.1 Time Zone Use the section below to configure the Barricade's system time. Select your timezone and configure the daylight savings option based on your location. This information is used for the time/date parental rules you can configure with the Barricade's Advanced Firewall.

  • Page 20: Password Settings

    7.4.2 Password Settings Use this section to configure the password and idle time-out setting for your Barricade Router. The default password for this router is "smcadmin". 7.4.3 Remote Management Use this section to configure the remote management feature of your Barricade Router so the web- management can be accessed from the Internet (WAN).

  • Page 21: Advanced Setup - Wan

    7.5 | Advanced Setup - WAN 7.5.1 Dynamic IP The cable modem option allows you to configure a host name and MAC Address. The Host Name is optional, but may be required by some ISPs. The default MAC address is set to the WAN’s physical interface on the Router.

  • Page 22: Pptp

    7.5.3 PPTP Point-to-Point Tunneling Protocol is a common connection method used for xDSL connections in Europe. It can be used to join different physical networks using the Internet as an intermediary. If you have been provided with the information as shown on the screen, enter the assigned IP address, subnet mask, default gateway IP address, user ID and password, and PPTP Gateway.

  • Page 23: Bigpond

    7.5.6 BigPond If you use the BigPond Internet Service which is available in Australia, enter your username and password and apply the changes. 7.6 | Advanced Setup - LAN This is the local IP address of the router. All networked computers must use the LAN IP address of the router as their default Gateway.

  • Page 24: Advanced Setup - Nat

    7.7 | Advanced Setup - NAT 7.7.1 | Virtual Server The firewall of the router filters out unrecognized packets to protect your intranet. This means that all network hosts are invisible to the outside world. However, some of the hosts can be made accessible by enabling the Virtual Server mapping.

  • Page 25: Special Applications

    7.7.2 | Special Applications Some applications require multiple connections, such as Internet games, video conferencing, and Internet telephony. These applications cannot work with a pure NAT router because of the firewall function. However, the Special Applications feature allows some of these applications to work with the router.

  • Page 26: Advanced Setup - Firewall

    7.8 | Advanced Setup - FIREWALL 7.8.1 | URL Blocking URL Blocking blocks LAN computers from accessing pre-defined Websites. The difference between the Domain Filter and URL Blocking is that the Domain filter requires you to enter a suffix (.com or .org), while URL Blocking requires you to enter only a keyword.

  • Page 27: Mac Filter

    7.8.2 | MAC Filter MAC Address Filtering allows you assign different access rights to various users and you can also assign a specific IP address to a certain MAC address. Select the Enable radio button to enable the MAC Address Control. All of the settings on this screen take effect when Enable is checked.

  • Page 28: Parental Control

    7.8.3 | Parental Control Using this option allows you to specify different privileges for the client PCs. This is an excellent tool to control a child's access to specific content and/or general internet access for a specific time and/or date. To setup a Parental Control Rule: Click on [Click here to configure a new Parental Control Rule] link.

  • Page 29: Dmz

    7.8.4 | DMZ If you have a local client PC that cannot run an Internet application properly from behind the NAT firewall, then you can open the client up to unrestricted two-way Internet access by defining a Virtual DMZ Host. 7.8.5 | Advanced Firewall Settings This section allows you to configure several advanced features for the Barricade™...

  • Page 30: Ddns (Dynamic Dns)

    7.9 | DDNS (Dynamic DNS) Dynamic DNS provides users on the Internet a method to tie their domain name(s) to computers or servers. DDNS allows your domain name to follow your IP address automatically by having your DNS records changed when your IP address changes. Before you can enable the Dynamic DNS, you need to register an account with one of the Dynamic DNS servers that are listed in the Provider field.

  • Page 31: Tools

    7.11 | Tools The Toolbox menu allows you to view your system logs, upgrade firmware, backup settings, restore settings to defaults, reboot the router, and access miscellaneous settings. 7.12 | Status You can use the Status screen to see the connection status for Barricade's WAN/LAN interfaces, firmware and hardware version numbers, any illegal attempts to access your network, as well as information on all DHCP client PCs currently connected to your network.

  • Page 32: Troubleshooting

    8 | Troubleshooting A. Verifying your connection to the router If you are unable to access the Router’s web-based administration pages, then you may not be properly connected or configured. To determine your TCP/IP configuration status, please follow the steps below: 1.
  • Page 33 New firmware revisions will be made available as necessary when new product features or functionality is released. You should check http://www.smc.com on a periodic basis for these updates. If a new version is available, check the release notes to be sure of what has been changed/added and then you can decide if you wish to complete the upgrade.

  • Page 34: Terminology

    9 | Terminology 10BaseT - Physical Layer Specification for Twisted-Pair Ethernet using Unshielded Twisted Pair wire at 10Mbps. This is the most popular type of LAN cable used today because it is very cheap and easy to install. It uses RJ-45 connectors and has a cable length span of up to 100 meters. There are two versions, STP (Shielded Twisted Pair) which is more expensive and UTP (Unshielded Twisted Pair), the most popular cable.
  • Page 35 IP addresses, so that when a domain name is requested (as in typing " www.smc.com" into your Internet browser), the user is sent to the proper IP address. The DNS server address used by the computers on your home network is the location of the DNS server your ISP has assigned.
  • Page 36 LAN - A communications network that serves users within a confined geographical area. It is made up of servers, workstations, a network operating system and a communications link. Servers are high-speed machines that hold programs and data shared by network users. The workstations (clients) are the users' personal computers, which perform stand-alone processing and access the network servers as required.
  • Page 37 PAP - This is a simple authentication protocol where the username and password data are both handled in a cleartext or unencrypted format. We do not recommend using PAP because your passwords are easily readable from the Point-to-Point Protocol (PPP) packets exchanged during the authentication process.

  • Page 38: Technical Specifications

    10 | Technical Specifications Below is an outline of the Technical Specifications for the Barricade™ 4-Port Cable/DSL Broadband Router. Standards 802.3, 802.3u WAN Port 1 - 10/100Mbps RJ45, with Auto MDI/MDIX LAN Port 4 - 10/100Mbps RJ45, with Auto MDI/MDIX Supported WAN type Static IP Dynamic IP...

  • Page 39: Compliances

    Classe B prescrites dans la norme sur le matériel brouilleur: « Appareils Numériques » NMB-003 édictée par le ministère des Communications EC Conformance Declaration – Class B SMC contact for these products in Europe is: SMC Networks Europe, Edificio Conata II, Calle Fructuós Gelabert 6-8, 2o, 4a,...
  • Page 40 This product complies with the requirements of theCouncil Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/68/ EEC. For the evaluation of the compliance with these Directives, the following standards were applied: Emission: EN 5022: 1998+A1:2000...

  • Page 41: Legal Information And Contacts

    SMC web site. Failure to register will not affect the standard limited warranty. The Limited Lifetime warranty covers a product during the Life of that Product, which is defined as a period of 5 years from the date of purchase of the product from SMC or its authorized reseller.
  • Page 42 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.
  • Page 43 Fax (65) 238 6466 Korea: 82-2-553-0860 Fax 82-2-553-7202 Japan: 81-45-224-2332 Fax 81-45-224-2331 Australia: 61-2-8875-7887 Fax 61-2-8875-7777 India: 91-22-8204437 Fax 91-22-8204443 If you are looking for further contact information, please visit www.smc.com. Model Number: SMC7004VBR 38 Tesla Irvine, CA 92618 Phone: (949) 679-8000...
