1. If you are using a printer driver that is set to 600 DPI, the printer data stream should
include a Unit of Measure PCL command set to 600. The command is
<ESC>&u600D
2. If the application controls the printer data stream, add the Unit of Measure command
early in the data stream. The command also affects X & Y positioning commands.
Add <ESC>&u600D
3. After calling the E-13B MICR font, issue a HMI (Horizontal Motion Index) command
set to 8 characters per inch. The command must be included with every E-13B
MICR font call using either the Selection String or ID call. The command string is:
<ESC>(10O<ESC>(s0p8h8v0s7b360T<ESC>&k15H font data
<ESC>(30802X<ESC>&k15H font data
See Font Mapping Appendix pages for specific character set data for each font.
PJL INFO MICR COMMAND
The ST Secure MICR Printer supports an optional custom bi-directional PJL Inquiry
Command. The command provides printer information and cartridge information for network
management. The command format is; @PJL
The command should be sent with UEL (Universal Exit Language) commands. Example:
<ESC>%-12345X
@PJL INFO MICR
<ESC>%-12345X
The following data is returned
@PJL INFO MICR
PRINTER STATE
SERIAL NUMBER
PAGECOUNT
CARTRIDGE TYPE
CARTRIDGE STATUS
CARTRIDGE SERIAL# = XXXXXXXX
TONER LEVEL
CARTRIDGE COUNT
LOW THRESHOLD
EMPTY THRESHOLD
ST Secure MICR Printer User's Guide
March 2006
INFO
UEL
INFO MICR Command
UEL
= READY
= BUSY
= NOT READY
= XXXXXXXX
= 123456
= NORMAL
= MICR
= UNKNOWN
= OK
= LOW
= EMPTY
= 0-9
= UNKNOWN
= XXXX
= XXXX
= XXXX
22
The Selection String
The ID Call
MICR
2006, Source Technologies
All Rights Reserved
