JMS Service Schematic

EXAMPLE 18–6
jms-service
|-- connection-factories [AKA conn. pools in the RA world]
| |-- connection-factory-1 (All CF stats for this CF)
|-- work-management (All work mgmt stats for the MQ-RA)
The ORB Tree
The ORB node holds monitorable attributes for connection managers. The following schematic
shows the top and child nodes for the ORB components. The nodes at which monitoring
statistics are available are marked with an asterisk (*). See
in an ORB" on page 185.

ORB Schematic

EXAMPLE 18–7
orb
|--- connection-managers
| |--- connection-manager-1 *
| |--- connection-manager-1 *
The Thread Pool Tree
The thread pool node holds monitorable attributes for connection managers. The following
schematic shows the top and child nodes for the ORB components. The nodes at which
monitoring statistics are available are marked with an asterisk (*). See
on page 186.

Thread Pool Schematic

EXAMPLE 18–8
thread-pools
| |--- thread-pool-1 *
| |--- thread-pool-2 *
About Statistics for Monitored Components and
Services
This section describes the monitoring statistics that are available:
"EJB Container Statistics" on page 176
■
"Web Container Statistics" on page 180
■
"HTTP Service Statistics" on page 181
■
"JDBC Connection Pools Statistics" on page 182
■
"JMS/Connector Service Statistics" on page 184
■
"Statistics for Connection Managers in an ORB" on page 185
■
Chapter 18 • Monitoring Components and Services
"Statistics for Connection Managers
"Thread Pools Statistics"
