About Monitoring
EXAMPLE 18–3
http-service *
The Resources Tree
The resources node holds monitorable attributes for pools such as the JDBC connection pool
and connector connection pool. The following schematic shows the top and child nodes for the
various resource components. The nodes at which monitoring statistics are available are
marked with an asterisk (*). See
EXAMPLE 18–4
resources
The Connector Service Tree
The connector services node holds monitorable attributes for pools such as the connector
connection pool. The following schematic shows the top and child nodes for the various
connector service components. The nodes at which monitoring statistics are available are
marked with an asterisk (*). See
EXAMPLE 18–5
connector-service
The JMS Service Tree
The JMS services node holds monitorable attributes for pools such as the connector connection
pool. The following schematic shows the top and child nodes for the various JMS service
components. The nodes at which monitoring statistics are available are marked with an asterisk
(*).
174 Sun GlassFish Enterprise Server 2.1 Administration Guide • December 2008
HTTP Service Schematic (Cluster and Enterprise Profile Version)
|---connection-queue *
|---dns *
|---file-cache *
|---keep-alive *
|---virtual-server-1*
| |--- request *
|---virtual-server-2*
| |--- request *

Resources Schematic

|---connection-pool1(either connector-connection-pool or jdbc)*
|---connection-pool2(either connector-connection-pool or jdbc)*

Connector Service Schematic

|--- resource-adapter-1
| |-- connection-pools
| | |-- pool-1 (All pool stats for this pool)
| |-- work-management (All work mgmt stats for this RA)
"JDBC Connection Pools Statistics" on page
"JMS/Connector Service Statistics" on page
182.
184.
