U-Line 2115R Service Manual page 96

2175R (2 of 2)
Item Part No.
Black
1 2303-S
2 2800
3 2694
4 31434-1
5 26091
6 41855
7 68092
8 68072-S
9 41992
10 41993
11 20026
12 66010
13 42162
14 26089
15 68059-01
16 68074
17 68080
18 21012-WHT
19 31726
20 31578
21 11508
22 31391-3
23 41156
24 41158
25 11835
26 31213
27 2333-S
Not N/A
Shown
Not N/A
Shown
Not 2950-01
Shown
**Part Includes Dryer & Process Tube
Part No. Part No.
White Stainless Steel
2303-S 2303-S
2800 2800
2694 2694
31434-1 31434-1
26091 26091
41855 41855
68092 68092
68072-S 68072-S
41992 41992
41993 41993
20026 20026
66010 66010
42162 42162
26089 26089
68059-01 68059-01
68074 68074
68080 68080
21012-WHT 21012-WHT
31726 31726
31578 31578
11508 11508
31391-3 31391-3
41156 41156
41158 41158
11835 11835
31213 31213
2333-S 2333-S
N/A 12091
N/A 14159-01
2950-01 2950-01
Description
Condenser Assembly**
Process tube
Dryer
Rivet, thermistor cover
Cover, thermistor
Screw, Evaporator
Thermistor, quick connect white
Circuit Board Assembly
Support, circuit board (included with 68072-S)
Support, circuit board (included with 68072-S)
Screw, reed switch
Reed Switch
Screw, 8-18 x .75, plastite
Housing, display
Display glass, Echelon control
Display Assembly, Echelon
Switch jumper (included with 68072-S)
Rivet, white
Formed drain tube
Washer, drain tube
Drain cup
Drain trough
Screw, stainless steel
Nut
Clamp, thermistor
Spacer, Evaporator
Evaporator Assembly**
Bushing, top pivot post
Commercial handle (SS accessory only)
Wire connector, 12-pin
Section 4 - Parts
4-17
