U-Line 2115R Service Manual page 94

2175R (1 of 2)
Item Part No.
Black
1 80-17060-01
2 N/A
3 23025
4 26070-01-S
5 42173-BLK
6 12094-01
7 11901-1-BLK-S
8 42161-ZP
9 11898-S-BLK
10 11899-S-BLK
11 31673-S
12 42101-BLK
13 42096
14 41604
15 80-29010-01
16 20033-BLK
17 2945
18 31686
19 N/A
20 11969
21 41342
22 31685
23 40021
24 40020
25 5400-S
26 2800
27 2694
28 31021
29 5411
30 5412
31 5400-CAP
32 5263-S
33 5188
34 41787
35 31550-1-S
36 31664
37 66016
38 20050
39 66019
40 11859
41 31317
42 2891-01
43 41319
44 2938-2
Part No. Part No.
White Stainless Steel
80-17060-02 80-17075-01
N/A 80-17075-02
23025 23025
26070-02-S N/A
42173-NAT N/A
12094-03 12094-02
11901-1-BLK-S 11994-BLK-S
42161-ZP 42161-ZP
11898-S-KIT 11995-S-SS
11899-S-KIT 11996-S-SS
31673-S 31673-S
42101-ZP 42101-SS
42096 42096
41725 N/A
80-29010-02 80-29010-03
20033-ZP 20033-ZP
2945 2945
31686 31686
N/A 14160-01
11969 11969
41342 41342
31685 31685
40021 40021
40020 40020
5400-S 5400-S
2800 2800
2694 2694
31021 31021
5411 5411
5412 5412
5400-CAP 5400-CAP
5263-S 5263-S
5188 5188
41787 41787
31550-1-S 31550-1-S
31664 31664
66016 66016
20050 20050
66019 66019
11859 11859
31317 31317
2891-01 2891-01
41319 41319
2938-2 2938-2
Description
Door Assembly, RH
Door Assembly, LH
Nameplate
Handle Assembly
Hole plug (included with handle assembly)
Gasket, door
Pivot plate
Screw, pivot plate
Hinge Assembly, top
Hinge Assembly, bottom
Door Closer Assembly
Screw, hinge (included with hinge assembly)
Pivot post (included with hinge assembly)
Screw, handle (included with handle assembly)
Grille
Screw (included with grille)
Jumper wire, power cord
Door Shelf
Towel Bar Handle Assembly
Back panel
Screw, back panel
Crisper drawer
Crisper shelf
Glass shelf
Compressor
Process tube (included with 5400-S)
Dryer (included with 5400-S)
Grommet (included with 5400-S)
Overload (included with 5400-S)
Relay (included with 5400-S)
Cover (included with 5400-S)
Fan motor, condenser
Fan blade, condenser
Nut (included with 5263-S)
Drain Pan Assembly
Tape (included with #35)
Magnet
Screw, magnet
Spacer, nylon
Lens, light housing
Light bulb, 10W, 120V
Light Socket Assembly
Foot, leveler
Power cord
Section 4 - Parts
4-15
