U-Line 2115R Service Manual page 82

CLR2160 (1 of 2)
Item Part No.
Black
1 80-17071-01
N/A
2 23025
3 26071-01-S
4 42173-BLK
5 12094-04-S
6 12095-04
7 11901-1-BLK-S
8 42161-ZP
9 11898-S-BLK
10 11899-S-BLK
11 31673-S
12 42101-BLK
13 42096
14 41604
15 80-29012-01
16 20033-BLK
17 P-60
18 14132-BLK
19 N/A
20 11964-02
21 41342
22 42125
23 N/A
24 41955
25 70081-S
26 2819
27 2693
28 31021
29 71027
30 71028
31 70081-CAP
32 5300
33 5303
34 41826
35 42114
36 2716-1
37 41254
38 404-CLR60
39 73002-2
40 73002-1-S
41 41319
42 2949
Not N/A
Shown
Part No. Part No.
White Stainless Steel
80-17071-02 80-17071-03
N/A 80-17071-13
23025 23025
26071-02-S N/A
42173-NAT N/A
12094-06-S 12094-05-S
12095-06 12095-05
11901-1-BLK-S 11994-BLK-S
42161-ZP 42161-ZP
11898-S-KIT 11995-S-SS
11899-S-KIT 11996-S-SS
31673-S 31673-S
42101-ZP 42101-SS
42096 42096
41725 N/A
80-29012-02 80-29012-03
20033-ZP 20033-ZP
P-60 P-60
14132-KIT 14132-SS
N/A 14160-01
11964-02 11964-02
41342 41342
42125 42125
N/A N/A
41955 41955
70081-S 70081-S
2819 2819
2693 2693
31021 31021
71027 71027
71028 71028
70081-CAP 70081-CAP
5300 5300
5303 5303
41826 41826
42114 42114
2716-1 2716-1
41254 41254
404-CLR60 404-CLR60
73002-2 73002-2
73002-1-S 73002-1-S
41319 41319
2949 2949
N/A 12091
Description
Door Assembly, RH
Door Assembly, LH
Nameplate
Handle Assembly
Hole plug (included with handle assembly)
Gasket, door
Gasket, center (included with gasket assembly)
Pivot plate
Screw
Hinge Assembly, top
Hinge Assembly, bottom
Door Closer Assembly
Screw, hinge (included with hinge assembly)
Pivot post (included with hinge assembly)
Screw, handle (included with handle assembly)
Grille
Screw (included with grille)
Waste Water Pump Kit
Front panel (board access)
Towel Bar Handle Assembly
Back panel
Screw, back panel
Cover, solid hole
Cover, perforated hole
Bushing, black
Compressor, EMY70HER
Process tube (included with 70081-S)
Dryer (included with 70081-S)
Grommet (included with 70081-S)
Overload (included with 70081-S)
Relay (included with 70081-S)
Cover (included with 70081-S)
Fan motor, condenser
Fan blade, condenser
Fitting, water line, 90°
Screw, water valve
Water valve
Compression nut (included with 404-CLR60
Water line
Coil only, Danfoss
Hot Gas Bypass Assembly
(includes dryer and process tube)
Foot, leveler
Power cord
Bushing, top pivot post
Section 4 - Parts
4-3
