U-Line 2115R Service Manual page 136

CO2175DWR/CO2275DWR (1 of 4)
Item Part No.
Black
1 80-29010-01
2 20033-BLK
3 11969
4 41342
5 26014
6 80-48001-00
7 26000
8 70081-FFS
9 2800
10 72018
11 31021
12 71027
13 71028
14 70081-CAP
15 5263-S
16 5188
17 41787
18 31550-1-S
19 31664
20 11859
21 31317
22 2891-01
23 41319
24 2946
25 41826
26 41893-ZP
27 2552A
28 41254
29 404-CO207DWR
30 73002-FFS
31 73002-2
32 2800
33 72018
34 14147-01
35 80-47002-00
Part No. Description
Stainless Steel
80-29010-03 Grille
20033-ZP Screw (included with grille)
11969 Back panel
41342 Screw, back panel
26014 Ice bucket
80-48001-00 Drawer Organizer Assembly
26000 Top crisper
70081-FFS Compressor
2800 Process tube
72018 Dryer
31021 Grommet
71027 Overload
71028 Relay
70081-CAP Cover
5263-S Fan motor, condenser
5188 Fan blade, condenser
41787 Nut (included with 5263-S)
31550-1-S Drain Pan Assembly
31664 Tape
11859 Lens, light housing
31317 Light bulb, 10W, 120V
2891-01 Light Socket Assembly
41319 Foot, leveler
2946 Power cord
41826 Fitting, brass, 90°
41893-ZP Screw
2552A Water valve
41254 Plastic Nut & Sleeve Assembly
404-CO207DWR Water Line Assembly
73002-FFS Hot Gas Valve Assembly, Danfoss
73002-2 Solenoid only (included with 73002-FFS)
2800 Process tube (included with 73002-FFS)
72018 Dryer (included with 73002-FFS)
14147-01 Splash guard
80-47002-00 Slide Assembly (set of 2)
Section 4 - Parts
4-57
