U-Line 2115R Service Manual page 118

2275DWRWS/2275DWRWOL (1 of 2)
Item Part No.
1 18066-Vinyl
2 12094-08-GREY
12094-07-BLK
3 14016
4 39004-03
5 41729
6 42106
7 42175
8 26018-02
9 14030-03
10 2953
11 14017
12 14030-04
13 14160-05
14 20046
15 23015
16 26023
17 35009
18 39006-03
19 42122
20 4816
21 23027-03
22 73002-2
23 80-48005-00
24 80-47001-00
25 2891-01
26 80-29010-01
Description
Wine Rack Assembly
Gasket, drawer, grey
Gasket, drawer, black
Front, top drawer
Wood front, top drawer
Pop rivet, stainless steel
Screw, wood
Pop rivet
Glass front, top drawer
Stainless steel wrap, top
Main wire to harness
Tub, bottom drawer
Stainless steel wrap, bottom
Towel Bar Handle Assembly
Screw
Washer, felt
Glass front, drawer
Transfer tape
Wood front display,
bottom drawer
Screw
Screw
Slide Assembly (set of 2)
Coil (included with 73002-S)
Wine Caddy Assembly
(includes items 4 & 6)
Drawer Slide Assembly
(set of 2)
Light Socket Assembly
Grille Assembly, black
Item Part No. Description
27 80-29010-03
28 20033-ZP
29 70077-S
30 2800
31 2694
32 31021
33 71009
34 71010
35 70077-CAP
36 41787
37 5263-S
38 5188
39 41319
40 31550-1-S
41 31664
42 2948
43 11859
44 31317
45 71013
46 73002-S
Not 66018-01
Shown
Not 80-50002-00
Shown
Not 14159-05
Shown
Section 4 - Parts
Grille Assembly, SS
Screw (included with grille)
Compressor Assembly
Process tube
(included with 70077-S
Dryer (included with 70077-S)
Grommet
(included with 70077-S)
Overload
(included with 70077-S)
Relay (included with 70077-S)
Cap (included with 70077-S)
Nut (included with 5263-S)
Fan motor, condenser
Fan blade
Foot, leveler
Drain Pan Assembly
Tape (included with #40))
Power cord
Lens, light housing
Light bulb, 10W, 120V
Capacitor
(included with 70077-S)
Refrigerator valve
Light switch
Overlay Bracket Assembly
Commercial handle
(SS accessory only)
4-39
