U-Line 2115R Service Manual page 116

2175DWRR/2275DWRR (2 of 2)
Item Part No.
Black
1 68092
2 68072-S
3 68080
4 41992
5 41993
6 2950-01
7 68074
8 68059-01
9 11508
11508-02
10 31578
31578-02
11 31726
12 2694
13 2800
14 2303-S
15 66010
16 20026
17 31434-1
31434-2
18 26091
26091-02
19 41855
41855-02
20 31213
21 2333-S
2333-02-S
22 31154
23 2694
24 2800
25 31391-6
31391-7
26 21012-WHT
21012-BLK
27 11835
28 41158
29 41156
41156-02
30 2953
31 2952
Not 26070-01-S
Shown
Not N/A
Shown
Part No. Description
Stainless Steel
68092 Thermistor, quick connect white
68072-S Circuit Board Assembly
68080 Switch jumper (included with 68072-S)
41992 Support, circuit board (included with 68072-S)
41993 Support, circuit board (included with 68072-S)
2950-01 Wire connector, 12-pin
68074 Display Assembly, Echelon
68059-01 Display glass, Echelon control
11508 Drain cup (white)
11508-02 Drain cup (black)
31578 Washer, drain tube (white)
31578-02 Washer, drain tube (black)
31726 Formed drain tube
2694 Dryer (included with 2303-S)
2800 Process tube (included with 2303-S)
2303-S Condenser Assembly
66010 Reed Switch
20026 Screw, reed switch
31434-1 Rivet, thermistor cover (white)
31434-2 Rivet, thermistor cover (black)
26091 Cover, thermistor (white)
26091-02 Cover, thermistor (black)
41855 Screw, evaporator (SS)
41855-02 Screw, evaporator (black)
31213 Spacer, evaporator
2333-S Evaporator Assembly, (white)
2333-02-S Evaporator Assembly, (black)
31154 Armaflex (included with 2333-02-SS)
2694 Dryer (included with 2333-02-S)
2800 Process tube (included with 2333-02-S)
31391-6 Drain trough (white)
31391-7 Drain trough (black)
21012-WHT Rivet, (white)
21012-BLK Rivet, (black)
11835 Clamp, thermistor
41158 Nut
41156 Screw (SS)
41156-02 Screw (black)
2953 Wire harness (from display to plug)
2952 Wire harness (base to plug)
N/A Full handle
14159-05 Commerical handle (SS accesory only)
Section 4 - Parts
4-37
