2175BEV/2175BEVOL/2175BEVOL2 (1 of 2)
Item Part No.
Overlay Door
1 N/A
2 N/A
3 80-17094-01
80-17104-11
4 41319
5 2891-01
6 12094-01
7 11994-BLK-S
8 42161-ZP
9 11995-S-BLK
10 11996-S-BLK
11 31673-S
12 42101-BLK
13 42096
14 31317
15 80-29010-01
16 20033-BLK
17 2945
18 16002
19 N/A
20 11969
21 41342
22 40010-12
23 25032-7
24 2938-2
25 5400-S
26 2800
27 2694
28 31021
29 5411
30 5412
31 5400-CAP
32 5263-S
33 5188
34 41787
35 31550-1-S
36 31664
37 66016
38 20050
39 66019
40 11859
41 31443-11
Not N/A
Shown
Part No. Description
Stainless Steel
80-17094-03 Door Assembly, RH
80-17094-13 Door Assembly, LH
N/A Overlay Door (Model U-2175BEVOL-00)
N/A Overlay Door (Model U-2175BEVOL2-00)
41319 Foot, leveler
2891-01 Light Socket Assembly
12094-02 Gasket, door
11994-BLK-S Pivot plate
42161-ZP Screw, pivot plate
11995-S-SS Hinge Assembly, top
11996-S-SS Hinge Assembly, bottom
31673-S Door Closer Assembly
42101-SS Screw, hinge (included with hinge assembly)
42096 Pivot post (included with hinge assembly)
31317 Light bulb, 10W, 120V
80-29010-03 Grille
20033-ZP Screw (included with grille)
2945 Jumper wire, power cord
16002 Hinge Backing Plate Assembly
14160-01 Towel Bar Handle Assembly
11969 Back panel
41342 Screw, back panel
40010-12 Glass shelf
25032-7 Edge trim, rear
2938-2 Power cord
5400-S Compressor, EMY130HER
2800 Process tube (included with 5400-S)
2694 Dryer (included with 5400-S)
31021 Grommet (included with 5400-S)
5411 Overload (included with 5400-S)
5412 Relay (included with 5400-S)
5400-CAP Cover (included with 5400-S)
5263-S Fan motor, condenser
5188 Fan blade, condenser
41787 Nut (included with 5263-S)
31550-1-S Drain Pan Assembly
31664 Tape (included with #35)
66016 Magnet
20050 Screw, magnet
66019 Spacer, nylon
11859 Lens, light housing
31443-11 Edge trim, front
14159-01 Commercial handle (SS accessory only)
