U-Line 2115R Service Manual page 106

2115WC/2115WCOL/2115WCOL2 (1 of 2)
Item Part No.
Black
1 80-17065-01
2 N/A
3 80-17081-01
80-17104-12
4 26088-6-BLK
5 42173-BLK
6 31493-8-BLK
7 11994-BLK-S
8 42161-ZP
9 11995-S-BLK
10 11996-S-BLK
11 31673-S
12 42101-BLK
13 42096
14 42174
15 80-29012-01
16 20033-BLK
17 2945
18 16002
19 N/A
20 11964-01
21 41342
22 2891-01
23 41319
24 2938-2
25 5400-S
26 2800
27 2694
28 31021
29 5411
30 5412
31 5400-CAP
32 5263-S
33 5188
34 41787
35 31385
36 66019
37 66016
38 20050
39 11859
40 31317
41 42125
42 42126
Not N/A
Shown
Part No. Description
Stainless Steel
80-17065-03 Door Assembly, RH
80-17065-13 Door Assembly, LH
N/A Overlay Door (Model U-2115WCOL-00)
N/A Overlay Door (Model U-2115WCOL2-00)
N/A Handle Assembly
N/A Hole plug (included with handle assembly)
31496-8-GRY Gasket, door
11994-BLK-S Pivot plate
42161-ZP Screw, pivot plate
11995-S-SS Hinge Assembly, top
11996-S-SS Hinge Assembly, bottom
31673-S Door Closer Assembly
42101-SS Screw, hinge (included with hinge assembly)
42096 Pivot post (included with hinge assembly)
N/A Screw, handle
80-29012-03 Grille
20033-ZP Screw (included with grille)
2945 Jumper wire, power cord
16002 Hinge Backing Plate Assembly
14160-01 Towel Bar Handle Assembly
11964-01 Back panel
41342 Screw, back panel
2891-01 Light Socket Assembly
41319 Foot, leveler
2938-2 Power cord
5400-S Compressor, EMY130HER
2800 Process tube (included with 5400-S)
2694 Dryer (included with 5400-S)
31021 Grommet (included with 5400-S)
5411 Overload (included with 5400-S)
5412 Relay (included with 5400-S)
5400-CAP Cover (included with 5400-S)
5263-S Fan motor, condenser
5188 Fan blade, condenser
41787 Nut (included with 5263-S)
13185 Drain Pan
66019 Spacer, magnet
66016 Magnet
20050 Screw, magnet
11859 Lens, light housing
31317 Light bulb, 10W, 120V
42125 Hole cover, perforated
42126 Hole cover, solid
14159-01 Commercial handle (SS accessory only)
Section 4 - Parts
4-27
