U-Line 2115R Service Manual page 100

2115R (2 of 2)
Item Part No.
Black
1 68092
2 68072-S
3 68080
4 41992
5 41993
6 2950-01
7 26086
8 68074
9 68059-01
10 26089
11 42162
12 2694
13 2800
14 2303-02-S
15 66010
16 20026
17 31434-1
18 26091
19 41855
20 31213
21 2878-01-S
22 31154
23 2694
24 2800
25 31391-4
26 21012-WHT
27 11508
28 31578
29 31726
30 11835
31 41158
32 41156
Not N/A
Shown
Not N/A
Shown
Part No. Part No.
White Stainless Steel
68092 68092
68072-S 68072-S
68080 68080
41992 41992
41993 41993
2950-01 2950-01
26086 26086
68074 68074
68059-01 68059-01
26089 26089
42162 42162
2694 2694
2800 2800
2303-02-S 2303-02-S
66010 66010
20026 20026
31434-1 31434-1
26091 26091
41855 41855
31213 31213
2878-01-S 2878-01-S
31154 31154
2694 2694
2800 2800
31391-4 31391-4
21012-WHT 21012-WHT
11508 11508
31578 31578
31726 31726
11835 11835
41158 41158
41156 41156
N/A 12091
N/A 14159-01
Description
Thermistor, quick connect white
Circuit Board Assembly
Switch jumper (included with 68072-S)
Support, circuit board (included with 68072-S)
Support, circuit board (included with 68072-S)
Wire connector, 12-pin
Liner, baseplate
Display Assembly, Echelon
Display glass, Echelon control
Housing, display
Screw, 8-18 x .75, plastite
Dryer (included with 2303-02-S)
Process tube (included with 2303-02-S)
Condenser Assembly
Reed Switch
Screw, reed switch
Rivet, thermistor cover
Cover, thermistor
Screw, Evaporator
Spacer, Evaporator
Evaporator Assembly
Armaflex (included with 27878-01-S)
Dryer (included with 27878-01-S)
Process tube (included with 27878-01-S)
Drain trough
Rivet, white
Drain cup
Washer, drain tube
Formed drain tube
Clamp, thermistor
Nut
Screw
Bushing, top pivot post
Commercial handle (SS accessory only)
Section 4 - Parts
4-21
