Tru Pointe® Ultra

2 Introduction

General Description

The Tru Pointe ® Ultra Ultrasonic Leak Detector is an electronic instrument that detects the
inaudible high frequency sound (ultrasound) of high pressure leaks and converts it to sound a
human can hear. Using patented technology, the Tru Pointe
quantifying the intensity of the ultrasound and converting it to sound the user can easily hear.
The Tru Pointe Ultra has been specifi cally designed for air conditioning and refrigeration
®
(HVAC-R) leak detection. The Tru Pointe
detect the vacuum and high pressure leaks that can occur in HVAC-R systems. Since the instru-
ment detects only sound, it is gas-independent and can be used to detect leaks at the speed of
sound, without the delay seen with gas dependent "sniffers."

What's in the Kit

0028-8000
®
Tru Pointe Ultra Kit
Tru Pointe Ultra ....................... 0028-7000
®
Instruction Manual .................... 0028-9000
Carrying Case........................... 0028-0005
6" Wave Guide .......................... 0028-0004
Touch Probe ............................. 0028-0003
Folding Hi-Fi Headset
w/ Volume Control .................... 0028-0002
9v Battery ................................. 0204-0024
Warranty Card .......................... 0006-8825

Features

• Capable of detecting a 5 psi leak from a .005" hole from 20-30 feet (depending on back-
ground noise.
• Capable of detecting any gas that generates ultrasonic sound during fl ow, including vacuum
leaks.
• Not affected by wind or high concentrations of leaked refrigerants.
• SoundBlaster ® allows testing of items not under pressure. (0028-8010 only)
2
Ultra guides the user to a leak by
®
Ultra is the only test system that can simultaneously
®
0028-8010
®
Tru Pointe Ultra Kit w/ SoundBlaster
Tru Pointe Ultra ....................... 0028-7000
®
SoundBlaster .......................... 0028-7006
®
Instruction Manual .................... 0028-9000
Carrying Case........................... 0028-0005
6" Wave Guide .......................... 0028-0004
Touch Probe ............................. 0028-0003
Folding Hi-Fi Headset
w/ Volume Control .................... 0028-0002
9v Battery ................................. 0204-0024
Warranty Card .......................... 0006-8825
Instruction 0028-9000
®
