58
MergePoint 5200 Service Processor Manager Installer/User Guide
Appendix D: How To Configure Virtual Serial Port
MergePoint 5200 service processor managers have the ability to access target devices with iLO
through the Virtual Serial port. To use this feature, you must enable the Virtual Serial port on both
the BIOS Serial Console and EMC Console. When Virtual Serial Port is enabled, it provides
remote access through the iLO management controller to the BIOS Serial Console.
To configure BIOS Serial Console:
1.
Enter ROM-Based Setup Utility by pressing
2.
Select BIOS Serial Console and EMS on the main menu.
3.
Press
Enter
4.
Select BIOS Serial Console Port on the options.
5.
Press
Enter
6.
Select Com1 or Com2 as the BIOS Serial Console Port.
7.
Press
Enter
To configure EMC Console:
1.
Enter ROM-Based Setup Utility by pressing
2.
Select BIOS Serial Console and EMS on the main menu.
3.
Press
Enter
4.
Select EMC Console on the options.
5.
Press
Enter
6.
Select the same port that you selected for the BIOS Serial Console Port.
7.
Press
Enter
to display the options.
to display the options of BIOS Serial Console Port.
to save the selection.
to display the options.
to display the options of EMC Console.
to save the selection.
during power up or system reset.
F9
during power up or system reset.
F9
