AT-610P User Manual
default config.
� Long Contact: Set more parameters in contact field.
� Click to Talk: Set click to Talk (need practical software support).
� Ban Anonymous Call: Set to ban Anonymous Call.
� Dial without Register: Set call out by proxy without registration.
� Enable Strict Proxy: Support the special SIP server-when phone receives
the packets sent from server， phone will use the source IP address, not the
address in via field.
� Rtp Encode: enable voice data encryption.
� Forward Type: Select call forward mode, the default is off.
� Off：Close down calling forward.
� Busy：If the phone is busy, incoming calls will be forwarded to the appointed
phone.
� No answer：If there is no answer, incoming calls will be forwarded to the
appointed phone.
� Always：Incoming calls will be forwarded to the appoint phone directly.
The phone will prompt the incoming while doing forward.
� Forward Phone Number: Appoint your forward phone number.
� Server Type: Select the special type of server which is encrypted, or has
some unique requirements or call flows.
Different VoIP Service providers may provide different modes.
� DTMF Mode: Select DTMF sending mode, there are three modes:
� DTMF_RELAY
� DTMF_RFC2833
� DTMF_SIP_INFO
� Transport Protocol: Set transport protocols, TCP or UDP.
� RFC Protocol Edition: Select SIP protocol version to adapt for the SIP server
which uses the same version as you select. For example, if the server is
CISCO5300, you need to change to RFC2543; else phone may not cancel
call normally. System uses RFC3261 as default.
� Enable Conference Num: conference ID.
� Subscribe Expire Time: Overtime of resending subscribe packet. Suggest
using the default config.
� Signal Encode: enable signal encryption.
� Enable Session Timer: enable rfc4028 to refresh the SIP sessions.
� Answer with Single Codec: only answer the call with a certain Codec.
� Auto TCP: enable TCP transmission protocol when the length of message
exceeds 1300 byte.
� Enable URI Convert: convert # into %23 when sending URI.
� Enable Display name Quote: Set to make quotation mark to display name as
the phone sends out signal, in order to be compatible with server.
� Enable GRUU: Set to support GRUU.
� Enable Subscribe: Enable Subscribe: Overtime of resending subscribe
packet. Suggest using the default config.
