- Page 1 SIP-50 SIP Proxy Server User’s Manual SIP Proxy Server SIP-50 User’s Manual...
-
Page 2: Ce Mark Warning
Copyright (C) 2005 PLANET Technology Corp. All rights reserved. The products and programs described in this User’s Manual are licensed products of PLANET Technology, This User’s Manual contains proprietary information protected by copyright, and this User’s Manual and all accompanying hardware, software, and documentation are copyrighted. -
Page 3: Table Of Contents
SIP-50 SIP Proxy Server User’s Manual Table of Contents CHAPTER 1：INTRODUCTION ........................1 1.1 F ..............................1 EATURES 1.2 P ..........................1 ACKAGE ONTENTS 1.3 SIP P ......................2 ROXY ERVER RONT 1.4 SIP P ......................3 ROXY ERVER ANEL 1.5 S... -
Page 4: Chapter 1：Introduction
SIP network by efficiently routing calls between application servers, voice gateways and IP endpoints. The SIP-50 will automatic NAT transversal for signaling and voice stream. User can setup the VoIP gateway or IP Phone in a private network easily, without the cumbersome settings of router. -
Page 5: Sip Proxy Server Front View
SIP-50 SIP Proxy Server User’s Manual 1.3 SIP Proxy Server Front View Front View: LCD Panel LED Panel LCD Panel: Used to make IP settings, view IP settings, reboot system, show service information, reset password and reset all configuration. It also show the average bandwidth usage for past 10 seconds when not in configuration mode. -
Page 6: Sip Proxy Server Rear Panel
SIP-50 SIP Proxy Server User’s Manual 1.4 SIP Proxy Server Rear Panel - Rear View: LAN Port Console Port Power On / Off switch Port Function This is where you will connect the AC Power power cord. 100~240VAC is allowed. -
Page 7: Specification
SIP-50 SIP Proxy Server User’s Manual 1.5 Specification Product SIP Proxy Server Model SIP-50 Hardware Connections 10/100Base-TX Button Hardware Reset LCD Panel 16x2 characters LCD System LED System: PWR, STATUS Network: ACT, LNK, 100 for LAN ports Power 100~240 VAC, 50~60Hz Operating Environment Temperature: 5~40°C... -
Page 8: Chapter 2：Hardware Installation
SIP-50 SIP Proxy Server User’s Manual Chapter 2：Hardware Installation 2.1 Installation Requirements Before installing the SIP Proxy Server, make sure your network meets the following requirements. - Mechanical Requirements The SIP Proxy Server can be installed anywhere in the network The SIP Proxy Server can be placed on the table or rack. -
Page 9: Install Sip Proxy Server To Your Network
SIP-50 SIP Proxy Server User’s Manual Install SIP Proxy Server to Your Network - Choose an Installation Site Select a suitable place on the network to install the SIP Proxy Server. - Connect LAN Cables Use standard LAN cables to connect your LAN side Switch or Hub to the LAN ports on SIP Proxy Server. -
Page 10: Chapter 3：Getting Started
SIP-50 SIP Proxy Server User’s Manual Chapter 3：Getting Started This chapter explains how to setup your computer to be a client to manage the SIP Proxy Server. 3.1 Initial Setup by LCD Panel 1. Press (ENTER) button to enter Select menu. - Page 11 SIP-50 SIP Proxy Server User’s Manual Open the web browser and type http://192.168.0.1:8888/. Machine will prompt for the login username/password, please log in SIP-50 with default user name is “admin”, password “123“. Then, you will enter SIP Proxy Server’s Configuration Menu.
-
Page 12: Chapter 4：Web Configuration
System settings menu contains three categories: “General” allows you to configure basic network parameters, Internet connection bandwidth and date/time. “MISC” allows you to define SIP-50 parameter, Prefix Route and Authorization which is needed for SIP network operation. “Admin” contains options to setup SNMP, backup / restore settings, upgrade firmware, etc. -
Page 13: Network
SIP-50 SIP Proxy Server User’s Manual 4.1.2 Network You can setup SIP Proxy Server network settings in this section. ♦ Host Name: Please assign a name that is easy to remember for SIP Proxy Server. ♦ Domain Name: Your local network domain name. The SIP Proxy Server will use this value as SIP Domain. -
Page 14: Config
SIP-50 SIP Proxy Server User’s Manual The Date/Time information will be used in the CDR system (refer to section 4.3). If your SIP Proxy Server can reach to the Internet, you can find the nearest NTP server in the Internet for your SIP Proxy Server that should provide the accurate date and time for the SIP Proxy Server. -
Page 15: Authorization
After clicking “New” or Modify button, the following prefix route record configuration page will be shown. ♦ Prefix Number: The Prefix number of URI that SIP-50 will match for. ♦ Destination Server: The SIP packet will forward to this server address. -
Page 16: Snmp
SIP-50 SIP Proxy Server User’s Manual ♦ Secret Key: The shared secret key with Radius server. ♦ Max Retry: The maximum times of resend request. ♦ Respose Time (sec): The maximum time to wait for a reply from the RADIUS server. - Page 17 SIP-50 SIP Proxy Server User’s Manual Note: It is strongly recommended to backup your file configuration file whenever you have complete the configurations. ♦ Restore: Press “Browse…” button to select the configuration file you have saved before. Then press “Start” button to start upload configuration file to SIP Proxy Server.
-
Page 18: Firmware Upgrade
SIP-50 SIP Proxy Server User’s Manual After confirm backup date and network settings, press “Restore” button to start restore all of the configurations to SIP Proxy Server. After restore is completed, a “Restore complete“ window prompts. Click “OK” to continue. -
Page 19: Reboot
SIP-50 SIP Proxy Server User’s Manual Note: For safety reason, it is strongly recommended to change the default password and store the password in a safe place. 4.1.12 Reboot You can reboot SIP Proxy Server from web and by Reset button on the rear side of this device. -
Page 20: Subscriber
SIP-50 SIP Proxy Server User’s Manual 4.2 Subscriber You can setup Subscriber and CDR in this section. 4.2.1 List The List function allows the administrator to configure user names and passwords on the proxy so that requests of SIP devices can be challenged before they are processed. The username and password entered here must match the username and password entered on the device. - Page 21 SIP-50 SIP Proxy Server User’s Manual Press “New” or Modify button, the link configuration page will be shown as the following. Please note that Phone number and Authorization Name must be unique. ♦ Phone Number: The sip phone number for this user. In the SIP protocol, this phone number will be a address with phone_number@your-domain.com...
-
Page 22: Phone Status
SIP-50 SIP Proxy Server User’s Manual 4.2.2 Phone Status The Phone Status will show all the phone of Subscriber List and it’s registration time. The administrator can see all SIP devices that have successfully registered with the SIP Proxy Server. Each row pertains to a single SIP device. -
Page 23: Export / Import
SIP-50 SIP Proxy Server User’s Manual 4.2.4 Export / Import This page allows you to export or import the subscriber list from a text file. ♦ Export User file: Export the subscriber data to a file named user_dump.txt in text format. - Page 24 SIP-50 SIP Proxy Server User’s Manual If this field is blank, the file will send the CDR file on the home directory of this ftp user account. E.g., C:\BACKUP FILE........................User ‘s Home C:\BACKUP FILE\AAA ......................Sub directory If you want send file on the home directory, please keep this field blank. If you want send file on the “AAA “...
-
Page 25: Daily Cdr
SIP-50 SIP Proxy Server User’s Manual ♦ Ending Date: The date of BYE method in SIP packet received by the SIP Proxy Server. This is the date the call complete. The date format is YYYY-MM-DD that YYYY is years, MM is months, and DD is days. - Page 26 SIP-50 SIP Proxy Server User’s Manual Chapter 5：Command Line Interface SIP Proxy Server has a built-in command menu. You can configure SIP Proxy Server by entering commands from menu. You can access the CLI from a SSH session or terminal emulator connected to the RS-232 port on the back panel.
-
Page 27: Command Menu
SIP-50 SIP Proxy Server User’s Manual Task Prompt Type From the remote host, run the ssh client and connect to your SIP Proxy Server by the IP None IP Address and port number is 22 address that you want to access When SIP Proxy Server prompts “login as:”,...
