Chapter 1: Explanation of the exterior Appearance
FRONT VIEW
REAR VIEW
Power LED: Lights up when drive is powered
HDD LED: Lights up when data is transmitted
IR LED: Blinks when a signal is received from the remote control
IR Receiver: Reception area of the remote control.
USB Port: Connect USB Cable to a PC in order to copy and paste data
DC Input: Connect
SV/5.1: Output for S-Video, Coaxial, Component (Y, Pr) signal.
A/V: Output for Composite, Stereo L-R, Component (Pb) signal.

Explanation of the exterior Appearance

Power LED IR LED
HDD LED
USB Port
DC Input
S-Video / Coaxial /
Component (Y, Pr)
DC Power Adaptor.
IR Receiver
Composite / Stereo L-R /
Component (Pb)
