USER MANUAL MODEL 1005 and 1005S Async. Carrier Sense Short Range Modem SALES OFFICE Part #07M1005-C Doc. #052031UC (301) 975-1000 Revised 4/29/98 TECHNICAL SUPPORT (301) 975-1007 An ISO-9001 http://www.patton.com Certified Company...
However, there is no guarantee that interference will not occur in a particular installation. If the Model 1005 does cause interference to radio or television reception, which can be...
19.2 Kbps, the Model 1005 requires no AC power or batteries. accessible DCE/DTE switch (see diagram below). If the device connected to the Model 1005 is a modem or multiplexer (or is wired like The Model 1005 has a unique carrier sense feature, which one), set the switch to “DTE”.
If your RS-232 application requires you to connect two pairs of bare wires to the Model 1005, you will need to open the case to access the terminal blocks. The following instructions will tell you how to open the case, connect the bare wires to the terminal blocks, and fasten the strain relief collar in place so that the wires won't pull loose.
Page 5
A ground wire is not necessary for proper operation of the Model 1005. When you finish connecting the wires to the terminal block, the Strip the outer insulation from the twisted pairs about one inch assembly should resemble the diagram below: from the end.
Page 6
DB-25 port of the RS-232 device. After doing so, remember to insert and tighten the two captive connector screws. Note: If you must use a cable to connect the Model 1005 to the RS-232, make sure it is a straight through cable of the shortest possible length—we recommend 6 feet or less.
Page 7
PATTON MODEL 1005 SPECIFICATIONS PATTON MODEL 1005 CABLE RECOMMENDATIONS Transmission Format: Asynchronous The Patton Model 1005 operates at frequencies of 20kHz or less and has been performance tested by Patton technicians using twisted- Data Rate: 0 to 19,200 bps (no strapping)
