- Page 1 USER MANUAL TS Series (Model 52X) Terminal Strip Surge Protectors Part# 07M52X-A SALES OFFICE Doc# 074170U (301) 975-1000 Revised 10/21/96 TECHNICAL SUPPORT (301) 975-1007 http://www.patton.com...
- Page 2 Networks (WANs), and data communications environments. Surge Support. energy is intercepted by a solid state hybrid circuit and diverted safely to chassis ground through a braided metal strap. The 52X-TS Series can handle repeated surge hits up to 1.5 k Watts without degrading its performance.
-
Page 3: Installation
Connect the wires to the terminal blocks. Use Figure 4 to is grounded, consult the manufacturer's user manual(s). ensure that each wire of the 52X-TS is connected to the correct corresponding pin number on the opposite side of the Open the case by inserting a screwdriver into the side of the case opening and gently turn the screwdriver. - Page 4 APPENDIX A MODEL 52X-ST SPECIFICATIONS Interface: RS-232, RS-422/485, Ethernet, Token Ring Connectors: Terminal Strip Wires Protected: 2, 4, 6, 8 or 10 Surge Capacity: 400A (8/20 µS) Clamp Voltage: Residual surge † @ 2 kV (1.2/50µS), 1 kA (8/20µS wave form [105 volts])
