Summary of Contents for Output Technology 4100
- Page 1 4100 PRINTER Replacement Parts Catalog...
- Page 2 Output Technology Corporation 3808 North Sullivan Road, Building 3 — Spokane, WA 99216 (509) 536-0468 We suggest you use genuine Output Technology parts and authorized service centers. Contact us at — (509) 536-0468 (Voice) or (509) 533-1280 (Fax) If you prefer, you can also contact us at —...
-
Page 3: Table Of Contents
GENERAL This catalog contains itemized lists of all servicing aids, supplies, expendables, and field replaceable parts for all models of the printer. Ordering information is provided for field replaceable units (FRUs). FRUs are illustrated at the end of this publication. Parts are listed in the following tables —... - Page 4 If applicable, have your Visa or MasterCard number and expiration date ready, and then contact Output Technology Corporation by phone, fax, or mail: 3808 North Sullivan Road, Building 3 Spokane, WA 99216 Phone: (509) 536-0468 Fax: (509) 533-1280 To order customer replaceable units (CRUs) or other miscellaneous items, select from the following table and then continue as directed in Step 4 above.
-
Page 5: Field Service Tools
FIELD SERVICE TOOLS (Recommended) Screwdrivers " Straight slot - #1 Phillips - #2 Phillips with 8”-to-10” shaft, such as Xcelite part number XST-102 Hex Allen wrench ", ", ", ", ", " " ball-end Allen wrench Open end wrenches or sockets ", ", ",... -
Page 6: Field Replaceable Units (Frus)
FIELD REPLACEABLE UNITS (FRUs) Model Item Figure FRU Part No. Description 4140 4130 Shaft, Lower Carriage 001-00021-00 001-00022-01 Shaft, Tractor, 1/4" 001-00027-02 Platen 001-00067-00 Shim, Printhead, .002" 001-00067-01 Shim, Printhead, .001" 001-00067-02 Shim, Printhead, .005” 001-00067-03 Shim, Printhead, .010” 001-00381-01 Shaft, Carriage Idler Pulley 001-00709-01 Shaft, Main Carriage... - Page 7 FRUs (Continued) Model Item Figure FRU Part No. Description 4140 4130 3a,4 021-00601-00 Head Carriage Assy, 132 Col 021-00602-00 Head Cable/Brkt Assy, 80 Col 021-00603-00 Head Cable/Brkt Assy, 132 Col 036-00037-00 Label, Head Gap Lever 040-00145-04 PCB, Main Logic (Version 1) 040-00159-00 PCB, Encoder 040-00162-03...
- Page 8 FRUs (Continued) Model Item Figure FRU Part No. Description 4140 4130 082-00031-01 Belt, 93T Pull Tractor 082-00035-00 Pulley, LF, 36T 082-00036-01 Pulley, LF, 20T 082-00327-01 Encoder Strip 082-00328-00 Belt, Carriage 082-00329-00 Pulley, Carriage, Idler, 20T 097-00018-00 Fuse Carrier, U.S. 097-00023-00 Fuse Carrier, International 097-00029-01 Switch, Interlock...
- Page 9 Figure 1. Enclosure JD0-A1...
-
Page 10: Base Assembly
Head Carriage Assembly not included in Mechanism Assembly. Illustration shows Item 33. Item 35.7 is similar. Figure 2. Base Assembly JD0-B2... -
Page 11: Printer Mechanism
Head Carriage Assembly not included in Mechanism Assembly. Figure 3a. Printer Mechanism (Complete) JD0-C1... -
Page 12: Carriage And Ribbon Drive Mechanism
Figure 3b. Carriage and Ribbon Drive Mechanism JD0-D... -
Page 13: Printhead Carriage
Head Carriage Assembly does not include Lower Carriage Bearing. Includes Printhead Cables, Encoder Cable, Cable Bracket and Clamp. † Includes most hardware for mounting bearing holders to frame of carriage. Figure 4. Printhead Carriage JD0-E2...
