Output Technology LaserMatrix 5 Replacement Parts Catalog

Hide thumbs

Advertisement

Quick Links

Download this manual
LaserMatrix
®
Models 5 & 6 Laser Printers
Replacement Parts Catalog

Advertisement

loading
Need help?

Need help?

Do you have a question about the LaserMatrix 5 and is the answer not in the manual?

Questions and answers

Related Manuals for Output Technology LaserMatrix 5

Summary of Contents for Output Technology LaserMatrix 5

  • Page 1 LaserMatrix ® Models 5 & 6 Laser Printers Replacement Parts Catalog...
  • Page 2 Xcelite is a registered trademark of Cooper Industries. Output Technology Corporation 3808 North Sullivan Road — Spokane, WA 99216 (509) 536-0468 We suggest you use genuine Output Technology parts and authorized service centers: Contact us at — Voice: (509) 536-0468 — Fax: (509) 533-1280 WWW: http://www.output.com Part No: 066-00441-01 Rev.

  • Page 3: Ordering Information

    GENERAL This catalog contains itemized lists of all servicing aids, supplies, expendables, and field replaceable parts for all models of the printer. Ordering information is provided for field replaceable units (FRUs). FRUs are illustrated at the end of this publication. Parts are listed in the following tables —...

  • Page 4: Customer Replaceable Units (Crus) And Miscellaneous

    If applicable, have your Visa or MasterCard number and expiration date ready, and then contact Output Technology Corporation by phone, fax, or mail: 3808 North Sullivan Road, Building 3 Spokane, WA 99216 Phone: (509) 536-0468 Fax: (509) 533-1280 To order customer replaceable units (CRUs) or other miscellaneous items, select from the following table and then continue as directed in Step 4 above.
  • Page 5 Service Center Supply Order Number Number Description Training and Publications (Continued) Manual, Operator's Guide, Models 5 and 6 NON-IMPACTCD100 Manual, Installation Guide, Models 5 and 6 Manual, Parts Catalog, Models 5 and 6 046-00207-00 —— Training Video Shipping 047-00014-00 —— Ship Kit Options, Upgrades, &...

  • Page 6: Field Replaceable Units (Frus)

    FIELD REPLACEABLE UNITS (FRUs) Qty Per Item Figure FRU Part No. Description Printer 021-00237-00 Laser Scan Unit (LSU) 021-00238-00 Fan, LSU, W/Plenum 021-00239-00 Kypd, Control Panel 021-00240-00 Base Pan 021-00241-00 Main Drive 107-00047-00 Motor, Stepper (Included in Main Drive Assy) 021-00242-01 Low Volt PWR Supply (120V) 021-00243-01...
  • Page 7 FIELD REPLACEABLE UNITS (FRUs) Qty Per Item Figure FRU Part No. Description Printer 046-00272-02 Mod5 ROM Card V7.09 046-00273-03 Mod6 ROM Card V8.08 —— SIMM (purchased from distributor) —— 001-00333-00 Contact, Earth Gnd 1,2,3 001-00452-00 Base Plate 001-00453-02 Plate, Fuser, Paper Guide 002-00264-00 Housing, Ozone Filter, Plenum 002-00265-00...
  • Page 8 FIELD REPLACEABLE UNITS (FRUs) Qty Per Item Figure FRU Part No. Description Printer 116-00046-00 Fuse, 10A, ¼ x 1-¼ (120V supply F2) 116-00027-00 Fuse, 3.15A, 5mm x 20mm (240V supply F1) 116-00047-00 Fuse, 6.3A, 5mm x 20mm (120V supply F1) 116-00101-00 Fuse, 4.0A, 5mm x 20mm (240V supply F2) 021-00276-00...
  • Page 9 Figure 1. Panels and Covers CD0-L Series 1000 2/23/98...
  • Page 10 Figure 2. FRU Parts and Assemblies (Top Side) CD0-M4 Series 1000 2/23/98...
  • Page 11 Series 1000 2/23/98...
  • Page 12 Figure 3. FRU Parts and Assemblies (Bottom Side) CD0-N3 Series 1000 2/23/98...
  • Page 13 Figure 4. Left Frame Assembly (Item 13), Detail CD0-O1 Series 1000 2/23/98...
  • Page 14 Figure 5. Low Voltage Power Supply (Item 6/7), Detail CD0-P Series 1000 2/23/98...
  • Page 15 Figure 6. Fuser Assembly CD0-BA Series 1000 2/23/98...
  • Page 16 Figure 7. Controller PCB CD0-BB Series 1000 2/23/98...

This manual is also suitable for:

Lasermatrix 6
