4200 Series (EuroLine )
Replacement Parts Catalog

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Euroline 4200 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Output Technology Euroline 4200 Series

Summary of Contents for Output Technology Euroline 4200 Series

  • Page 1 4200 Series (EuroLine ) Replacement Parts Catalog...

  • Page 2: Parts And Service

    Contact us at: Voice: (509) 536-0468 — Fax: (509) 533-1280 Output Technology maintains a Bulletin Board System (BBS) service. In the U.S.A., call (509) 533-1217 to access our BBS service for the very latest, up-to-date drivers, firmware, pricing, maintenance and troubleshooting aids, and application information. Also, you can contact us FTP: ftp.output.com/public/output...

  • Page 3: Ordering Information

    Obtain the serial number of your printer (on the back of the printer). If applicable, have your American Express, Visa or MasterCard number and expiration date ready, and then contact Output Technology Corporation by phone, fax, or mail: 2310 North Fancher Road...

  • Page 4: Customer Replaceable Units (Crus) And Miscellaneous

    To order customer replaceable units (CRUs) or other miscellaneous items, select from the following table and then continue as directed in Step 4 on page 1. CUSTOMER REPLACEABLE UNITS (CRUs) AND MISCELLANEOUS Part Number Description Qty Per Printer Customer Replaceable Units (CRUs) 020-00148-XX Cord, Power, UK 021-00343-XX...

  • Page 5: Field Service Tools

    FIELD SERVICE TOOLS Screwdrivers #1 Straight slot #2 Straight slot #1 Phillips #2 Phillips Hex Allen wrenches ", ", ", ", ", " Open end wrenches or sockets ", ", ", " Diagonal cutters Needle nose pliers C-ring and E-ring tools 4200 (EuroLine) Parts Catalog...

  • Page 6: Field Replaceable Units (Frus)

    FIELD REPLACEABLE UNITS (FRUs) Model Item Fig. FRU Part No. Description 001-00055-XX Shaft, Square Paper Drive 001-00381-XX Shaft, Carriage Idler Pulley 046-00853-XX Wire Form 046-00854-XX Wire Form 001-00390-XX Lever, Load Forms 001-00569-XX Lever, Interlock Switch 001-00633-XX Shaft, Carriage Idler Pulley 001-00645-XX Spring, Platen Cam Return 001-00656-XX...
  • Page 7 FRUs (Continued) Model Item Fig. FRU Part No. Description 021-00385-XX Forms Compressor, Mylar - Assy 021-00386-XX Keyboard, Twinax 021-00387-XX Keyboard, Coax 046-00309-XX Kit, Mechanism 021-00449-XX Motor, Carriage - Assy 046-00308-XX Kit, Mechanism 046-00307-XX Kit, Mechanism 021-00513-XX Wiper, Linear Scale 021-00517-XX Cable Set, Printhead (4 Cables) 5a&b 021-00518-XX...
  • Page 8 FRUs (Continued) Model Item Fig. FRU Part No. Description 58.9 046-00210-XX Tractors, Right & Left, W/O sensor 046-00211-XX PCB, Motor Driver 046-00212-XX PCB, Printhead Driver 046-00215-XX PCB, Serial 046-00216-XX Switch, Paper Out - Assy 046-00242-XX PCB, Digital - Assy 046-00251-XX Tractor Set, W/Sensor 64.5 5a&b...
  • Page 9 FRUs (Continued) Model Item Fig. FRU Part No. Description 082-00283-XX Belt, Carriage 082-00293-XX Brush, Linear Scale 082-00313-XX Spring, Carriage Idler 86.5 097-00018-XX Fuse Carrier, Domestic (EMI Filter) 097-00023-XX Fuse Carrier, Intl. (EMI Filter) 097-00027-XX Switch, Paper Load Lever 097-00031-XX Switch, Rocker, Power 097-00077-XX Cap, Starting, Inlet, Blower 097-00080-XX...
  • Page 10 Figure 1. Cabinet (Upper) DD0-Y3 4200 (EuroLine) Parts Catalog...
  • Page 11 Note: Cabinet top does not include the control panel, holder for the operator's guide, and hardware (except for the bracket) for attaching the cabinet top to the cabinet base. Figure 1a. Cabinet Top DD0-DA 4200 (EuroLine) Parts Catalog...
  • Page 12 Figure 2. Cabinet (Lower) DD0-Z1 Figure 3. Power Receptacle (EMI Filter) DD0-AA1 4200 (EuroLine) Parts Catalog...
  • Page 13 Figure 4a. Printer Mechanism (021-00507-00 & 021-00509-00) DD0-AB3 4200 (EuroLine) Parts Catalog...
  • Page 14 Figure 4b. Printer Mechanism (021-00447-01) DD0-BA2 4200 (EuroLine) Parts Catalog...
  • Page 15 Note: This illustration shows a printhead carriage for a Model 600, which is a three-printhead printer. Item numbers are also included in this illustration for a Model 400, which is a two-printhead printer. Figure 5a. Printhead Carriage DD0-AC1 4200 (EuroLine) Parts Catalog...
  • Page 16 Note: This illustration shows a printhead carriage for a Model 600, which is a three-printhead printer. Item numbers are also included in this illustration for a Model 400, which is a two-printhead printer. Figure 5b. Printhead Carriage DD0-BB 4200 (EuroLine) Parts Catalog...
  • Page 17 Figure 5c. Printhead Carriage (Model 800) DD0-BC 4200 (EuroLine) Parts Catalog...
  • Page 18 Note: Illustration shows the card cage for a Model 400. Card cages, cards, and cables are similar for Models 600 and 800. Item numbers are included for all models. Figure 6. Card Cage DD0-AD1 4200 (EuroLine) Parts Catalog...
  • Page 19 Figure 7. Transformer Assembly DD0-AE1 4200 (EuroLine) Parts Catalog...

This manual is also suitable for:

Euroline 400Euroline 600Euroline 800
