- Page 1 ® TriMatrix Printer OTC850 / OTC560 / 850XLE Replacement Parts Catalog...
- Page 2 Output Technology Corporation 3808 N Sullivan Rd Bldg 3 — Spokane, WA 99216 (509) 536-0468 We suggest you use genuine Output Technology Corporation supplies and authorized service centers. Contact us at — Voice: (509) 536-0468 — Fax: (509) 533-1280 For service, please have your printer model and serial numbers handy — these are located on the back of the printer.
-
Page 3: Table Of Contents
GENERAL This catalog contains itemized lists of all servicing aids, supplies, expendables, and field replaceable parts for all models of the printer. Ordering information is provided for field replaceable units (FRUs). FRUs are illustrated at the end of this publication. Parts are listed in the following tables —... -
Page 4: Customer Replaceable Units (Crus) And Miscellaneous
If applicable, have your Visa or MasterCard number and expiration date ready, and then contact Output Technology Corporation by phone, fax, or mail as instructed on the inside cover of this publication. EXPEDITE FEE POLICY It is the policy of Output Technology to charge a $50 Expedite Fee for guaranteed same day shipment, provided stock is available and confirming order is received via fax by 12:00pm, Pacific Time. -
Page 5: Field Service Tools
CRU & Miscellaneous (Continued) Part Number Description Qty Per Printer Spares Kit Optional Enhancements and Accessories 046-00080-00 NVRAM, 32K 046-00082-00 RAM, Static, 32K 021-00536-00 Paper Motion Detector Training and Publications IMPACTCD100 Manual, Operator’s Guide & Parts Catalog 066-00508-00 Manual, Maintenance & Parts 066-00422-02 Manual, Drawing Set Shipping... -
Page 6: Field Replaceable Units (Frus)
FIELD REPLACEABLE UNITS (FRUs) Model Spares Item Fig. FRU Part No. Description 001-00021-00 Shaft, Lower Carriage------------------------ 001-00022-01 Shaft, Tractor, 1/4"---------------------------- 001-00027-02 Platen -------------------------------------------- 001-00067-00 Shim, Printhead, .002" ----------------------- 001-00067-01 Shim, Printhead, .001" ----------------------- 001-00067-02 Shim, Printhead, .005” ----------------------- 001-00067-03 Shim, Printhead, .010” ----------------------- 001-00381-01 Shaft, Carriage Idler Pulley ----------------- 001-00709-01... - Page 7 FRUs (Continued) Model Spares Item Fig. FRU Part No. Description 036-00037-00 Label, Head Gap Lever-------------------- 040-00067-01 PCB, Jam Sensor Daughter-------------- 040-00090-03 PCB, Main Logic -------------------------- 040-00164-00 PCB, Keypad--------------------------------- 043-00159-04 EPROM---------------------------------------- 37.3 043- EPROM---------------------------------------- 37.7 046-00058-01 Tractors (w/o Jam Sensor & Cable) ---- 046-00118-00 Printhead -------------------------------------- 046-00201-00...
- Page 8 FRUs (Continued) Model Spares Item Fig. FRU Part No. Description 097-00041-00 Switch, Paper Out----------------------------- 107-00111-00 Fan ----------------------------------------------- 110-00029-00 Rectifier, Bridge, 35 a. ----------------------- ------------ 116-00021-00 Fuse, 3 a., Slow Blow, 3AG ------- 116-00022-00 Fuse, 1.6 a., Time-Delay, Metric OTC560 / OTC850 / 850XLE SEE NUMERIC LISTING FOR PRICING...
-
Page 9: Enclosure
Figure 1a. Enclosure (850XLE) AD2-BB2 OTC560 / OTC850 / 850XLE SEE NUMERIC LISTING FOR PRICING... - Page 10 Figure 1b. Enclosure (OTC560 / OTC850) AD2-CA OTC560 / OTC850 / 850XLE SEE NUMERIC LISTING FOR PRICING...
-
Page 11: Base Assembly
Head Carriage Assembly not included in Mechanism Assembly. Normally, an 8K Static RAM. (See table of CRUs and Miscellaneous for optional RAM.) Figure 2. Base Assembly AD2-CB OTC560 / OTC850 / 850XLE SEE NUMERIC LISTING FOR PRICING... -
Page 12: Printer Mechanism
Head Carriage Assembly not included in Mechanism Assembly. Figure 3a. Printer Mechanism (Complete) AD2-BC3 OTC560 / OTC850 / 850XLE SEE NUMERIC LISTING FOR PRICING... -
Page 13: Carriage And Ribbon Drive Mechanism
Figure 3b. Carriage and Ribbon Drive Mechanism AD2-BD1 OTC560 / OTC850 / 850XLE SEE NUMERIC LISTING FOR PRICING... -
Page 14: Printhead Carriage
Head Carriage Assembly does not include Lower Carriage Bearing. Includes Printhead Cables, Cable Bracket, and Clamp. † Includes most hardware for mounting bearing holders to frame of carriage. Figure 4a. Printhead Carriage (OTC850 / 850XLE) AD2-BE2 OTC560 / OTC850 / 850XLE SEE NUMERIC LISTING FOR PRICING... - Page 15 Head Carriage Assembly does not include Lower Carriage Bearing. Includes Printhead Cables, Cable Bracket, and Clamp. † Includes all hardware for mounting bearing holders to frame of carriage. Figure 4b. Printhead Carriage (OTC560) AD2-CC OTC560 / OTC850 / 850XLE SEE NUMERIC LISTING FOR PRICING...
