  • Page 1 Installation Operation Maintenance Energy Wheels for T-Series Climate Changer™ Air Handlers CLCH-SVX01B-EN August 2001...
  • Page 2 © 2001 American Standard Inc. All rights reserved...
  • Page 3: Table Of Contents

    Contents General Information..........4 Installation ..............8 Wiring ............... 13 Operation ..............14 Routine Maintenance..........16 Service and Repair ..........21 Troubleshooting ............25 CLCH-SVX01B-EN...
  • Page 4: General Information

    General Information Warnings and Cautions Notice that Warning and Caution appear at appropriate places in this manual. WARNING ...indicates a potentially hazardous situation that could result in death of serious injury. CAUTION ...alerts you to conditions that may result in minor or moderate injury or equipment damage.
  • Page 5 Two additional access doors are provided for service access into the outside/supply air section. The two access doors are accessible from the inside of the air handler. The energy wheel cassette is permanently installed in the section. In all but the 1500 CFM wheel size, the individual segments of the energy wheel are removable for cleaning or replacement.
  • Page 6 • Open the access door and check for internal, hidden damage. Concealed damage must be reported within 15 days of receipt. The Trane Company is not responsible for shipping damage. • Locate the hardware kit. Examine the energy wheel motor, drive, and energy transfer segments for damage.
  • Page 7 If needed, cover with a canvas tarp. The Trane Company warranty does not cover equipment damage due to negligence during storage.
  • Page 8: Installation

    Installation CAUTION Do not lift the unit from the top! Lift only from lifting lugs located at the bottom of the unit. Failure to do so may cause product or property damage. Section Weights and Dimensions Refer to Figure 2, Figure 3, Table 1, and Table 2 for section dimen- sions and weights.
  • Page 9 Figure 3. Dimensional data, side elevation CLCH-SVX01B-EN...
  • Page 10 27.63 36.88 114.13 3484 1. Section dimensions and weights subject to change without notice. Refer to Trane submittals for current dimensions and weights. Table 2. Energy wheel section dimensions (inches) and weights: partial outside air Section Dimensions Outside Air Hood...
  • Page 11 Rigging/Lifting Refer to the T-Series installation and maintenance manual, CLCH- IM-16A, for instructions on equipment rigging and lifting. It ships inside the air handler fan section. WARNING HEAVY OBJECT! Follow good lifting practices before lifting the unit. These include following instructions in the T-Series installation and maintenance manual, CLCH-IM-16A, estimating the center of gravity, and test lifting the unit to check balance and stability.
  • Page 12 Refer to Table 5 for the actuator sizing requirements for Traq™ dampers. Traq dampers are optional dampers that measure the outside air CFM. The torque values specified are for each side. Table 5. Traq™ damper torque requirements (lb-in) per side Unit Size 8 Torque CLCH-SVX01B-EN...
  • Page 13: Wiring

    Wiring Energy Wheel Motor A separate power source for the energy wheel motor is required. The energy wheel section is provided with fuses, a disconnect switch, and a starter located in the exhaust fan starter cabinet. The power connection for the energy wheel motor is made to a terminal block at this point.
  • Page 14: Operation

    Operation WARNING TOXIC HAZARDS! Do not use an energy wheel in an application where the exhaust air is contaminated with harmful toxins or biohazards, which could result in death or serious injury. WARNING HAZARDOUS VOLTAGE! Disconnect the electrical and remote disconnects before servicing. Do not open the service access doors while the unit is operating.
  • Page 15 the diameter seals away from the surface of the wheel. Apply power to confirm free wheel rotation. Re-adjust and tighten the seals according to instructions in the “Service and Repair” section on page 21. Figure 4. Segment retainers Figure 5. Belt tracking Damper Actuators (if so equipped): Stroke the actuators to observe full open and full closure of the dampers.
  • Page 16: Routine Maintenance

    Wash the segments or the wheel in a five-percent solution of non-acid-base coil cleaner (part no. CHM00021 at your local Trane parts center) or in a alkaline detergent and warm water. Soak the segments in the solution until grease, oil, and tar deposits are loosened.
  • Page 17 WARNING Always keep hands away from the bearing support beam when installing or removing segments. Failure to do so could result in serious injury. High-maintenance applications may benefit from keeping a spare set of clean segments on hand. This allows for rapid change-out of clean segments with minimal downtime.
  • Page 18 Figure 6. Energy wheel segment retainer and retaining catch Figure 7. Segment removal Segment Replacement WARNING HAZARDOUS VOLTAGE! Disconnect all electrical and remote disconnects before servicing. Do not open the service access doors while the unit is operating. Failure to disconnect all electrical power before servicing could result in death or serious injury.
  • Page 19: Cleaning The Energy Wheel Motor

    With the embedded stiffener facing the motor side, insert the nose of the segment between the hub plates. Holding the segment by the two outer corners, press the segment toward the center of the wheel and inward against the spoke flanges. If hand pressure does not fully seat the segment, insert the flat tip of a screwdriver between the wheel rim and the outer corners of the segment and apply gentle force while guiding the segment into place.
  • Page 20: Bearing And Motor Lubrication

    Filtration Debris screens are provided on the energy wheel section to prevent debris from entering the energy wheel section. Inspect these screens monthly and clean them as necessary. Bearing and Motor Lubrication The wheel drive motor and wheel support shaft bearings are permanently lubricated and no further lubrication is necessary.
  • Page 21: Service And Repair

    Service and Repair Bearing and Drive Belt Replacement WARNING HAZARDOUS VOLTAGE! Disconnect all electrical and remote disconnects before servicing. Do not open the service access doors while the unit is operating. Failure to disconnect all electrical power before servicing could result in death or serious injury.
  • Page 22 CAUTION SHARP EDGES! Protect hands and the belt from possible sharp edges of the hole in the bearing support beam. Failure to do so may result in minor or moderate injury or product damage. CAUTION Before laying across the energy wheel, place a rigid board across the span of the energy wheel cassette.
  • Page 23: Seal Adjustment

    17 Re-install the diameter seals or hub seal and tighten the retaining screws. 18 Adjust the seals per the “Seal Adjustment” procedure. 19 Rotate the wheel in a clockwise direction to confirm that the wheel rotates freely with a slight drag on the seals. 20 Re-install the bearing locking collar.
  • Page 24: Drive Motor And Pulley Replacement

    Adjust the seals toward the wheel surface until slight friction on the paper feeler gauge is felt when the gauge is moved along the length of the spoke. Check the seal adjustment through a full rotation of the wheel. Retighten the adjusting screws and recheck the clearance with the paper feeler gauge.
  • Page 25: Troubleshooting

    Troubleshooting WARNING HAZARDOUS VOLTAGE! Disconnect all electrical and remote disconnects before servicing. Do not open the service access doors while the unit is operating. Failure to disconnect all electrical power before servicing could result in death or serious injury. WARNING ROTATING PARTS! Disconnect all electrical and remote disconnects before servicing.
  • Page 26 Use Table 7 to aid in troubleshooting problems. Table 7. Troubleshooting energy wheels Symptom Probable Cause Recommended Action Wheel will not rotate Motor is not running The fuse or circuit breaker may be blown or open. Check the breaker/fuse box and replace.
