DSC Power832 PC5015 Instruction Manual

DSC Power832 PC5015 Instruction Manual

V2.7u and higher
Hide thumbs Also See for Power832 PC5015:
Table of Contents

Advertisement

Quick Links

WARNING
This manual contains information on limitations regarding product use and function and
information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.
I n s t r u c t i o n
M a n u a l
®
®
PC5O15
v2.7U and higher

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power832 PC5015 and is the answer not in the manual?

Questions and answers

Related Manuals for DSC Power832 PC5015

Summary of Contents for DSC Power832 PC5015

  • Page 1 WARNING This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read. I n s t r u c t i o n M a n u a l ®...

  • Page 2: About Your Security System

    General System Operation Your security system is made up of a DSC Power832 control panel, one or more Power832 keypads and various sensors and detectors. The control panel will be mounted out of the way in a utility closet or in a basement.

  • Page 3: System Information

    System Information Fill out the following information for future reference and store this manual in a safe place. Access Codes Your Master Code is: _________________________________________ Additional Access Codes: 01 __________________ 09 ____________________ 17 ____________________ 25 ________________ 02 __________________ 10 ____________________ 18 ____________________ 26 ________________ 03 __________________...
  • Page 4 ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ ___________________________________________ _____________________________________ [F] FIRE __________________________________________ [A] AUXILIARY ____________________________________ [P] PANIC ________________________________________ The Exit Delay Time is _______ seconds.

  • Page 5: Access Codes

    Access Codes Access codes are used to arm and disarm the system. There are 37 access codes available: 1 master code, 32 regular access codes, 2 duress codes and 2 partition master codes. Ask your installer for more information on using the duress and partition master codes. Only the Master Code can be used to program additional security codes and to change other system features as well as to arm and disarm the security system.

  • Page 6: Alternate Arming Methods

    Arming Using Push to Set or Final Door Set Zones If a Push to Set or Final Door Set Zone is used, an infinite exit delay will be initiated when the system is armed. In order to complete the arming sequence, the push to set or final door set zone must be violated and restored. When arming, once the Exit Delay has expired, the system will allow 5 seconds for detectors to settle before the system is armed.

  • Page 7: Disarming The System

    Quick Exit When the Quick Exit feature is enabled, pressing [ ][0] while the system is armed will provide a two minute window for you to exit the premises. During this time, you may only open and close the designated Entry/Exit door once. Once the door is closed, the panel will end the two minute quick exit delay.

  • Page 8: If An Alarm Sounds

    NOTE: If you return and find that an alarm has occurred while you were away, it is possible that an intruder may still be on the premises. Go to a neighbour's house, and call the local police to investigate. The alarm memory is cleared each time the panel is armed so that any alarms showing are alarms that occurred only during the last armed period.
  • Page 9 PC5532(Z) LED Keypad PC5508(Z), PC5516(Z) and PC5532(Z) Keypads: Press the keys on the number pad to view alarms or troubles, to Arm/Disarm the system or to bypass zones. To exit, press [#]; to select a function, press [ ]. PC5508(Z) LED Keypad PC5516(Z) LED Keypad The PC5508, PC5508Z, PC5516 and PC5516Z Keypads are available for applications with fewer than 32 zones.
  • Page 10 LCD5500(Z) Keypad All Keypads: Function Keys (Stay, Away, Chime, Reset, Exit): If activated by your installer, these keys allow easy single button activation of the most commonly used features. For more information, talk to your alarm installer. Press both Keys for two seconds to send a FIRE transmission.
  • Page 11 Programming codes from an LCD Keypad: Master Code Press the [ ] key to enter the function list. Scroll (< >) to... Press (*) for <> Press [5] or [ ]. The display will read... Access Codes Enter Master Enter your current Master Code. The display will read... Access Code (*) to Edit <...

  • Page 12: Zone Bypassing

    Zone Bypassing The zone bypassing function is used when access is needed to part of the protected area while the system is armed. Zones which are temporarily out of service due to damaged wiring or contacts may be bypassed to allow system arming until repairs can be made. Bypassed zones will not cause an alarm. Zones cannot be bypassed once the system is armed.

  • Page 13: Viewing Trouble Conditions

    Viewing Trouble Conditions The control panel continuously monitors a number of possible trouble conditions. If one of these trouble conditions occur, the keypad will beep twice every 10 seconds until you press any key on the keypad. NOTE: A TROUBLE condition reduces the security your system is designed to provide. Call your installing company for service.

  • Page 14: Setting The System Date And Time

    Setting the System Date and Time To set the system time, enter [ ] [6] followed by the Master Code. Press [1]. The keypad will now accept 10 consecutive digits: • Enter the Time in Hours and Minutes using the 24 Hour format (00:00 to 23:59). •...

  • Page 15: Door Chime Feature

    Door Chime Feature The door chime feature is used, while the panel is disarmed, to provide a tone from the keypad each time a door or window is opened or closed. The doors and windows which will provide this indication are programmed by your installer.

  • Page 16: Fire Alarm Operation

    Fire Alarm Operation Alarm On a fire alarm, the bell or siren will pulse ON and OFF. The transmission of the alarm to the central station is delayed for 30 seconds. If the alarm is not cleared within the 30 second delay, it will then be transmitted to the central station.

  • Page 17: Fire Escape Planning

    Fire Escape Planning There is often very little time between the detection of a fire and the time it becomes deadly. It is thus very important that a family escape plan be developed and rehearsed. 1. Every family member should participate in developing the escape plan. 2.
  • Page 18 FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Digital Security Controls Ltd. could void your authority to use this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 19: Note To Installers

    WARNING Please Read Carefully Smoke Detectors Smoke detectors that are a part of this system may not properly alert occupants Note to Installers of a fire for a number of reasons, some of which follow. The smoke detectors This warning contains vital information. As the only individual in contact may have been improperly installed or positioned.

  • Page 20: Limited Warranty

    LIMITED WARRANTY Digital Security Controls Ltd. warrants the original purchaser that for Digital Security Controls Ltd.’s liability for failure to repair the prod- a period of twelve months from the date of purchase, the product shall uct under this warranty after a reasonable number of attempts will be be free of defects in materials and workmanship under normal use.
