Draytek Vigor2820 Series User Manual page 16

Interface
Wireless LAN
ON/OFF/WPS
Factory Reset
LAN (1-4)
DSL
WAN 2
USB
PWR
ON/OFF
Vigor2820 Series User's Guide
Description
Press "Wireless LAN ON/OFF/WPS" button for 2 seconds to wait for client
device making network connection through WPS.
Press "Wireless LAN ON/OFF/WPS" button once to enable (WLAN LED
on) or disable (WLAN LED off) wireless connection.
Restore the default settings. Usage: Turn on the router (ACT LED is
blinking). Press the hole and keep for more than 5 seconds. When you see
the ACT LED begins to blink rapidly than usual, release the button. Then the
router will restart with the factory default configuration.
Connecters for local networked devices.
Connecter for accessing the Internet through ADSL2/2+.
Connecter for remote networked devices.
Connecter for a USB device (for 3G USB Modem or printer).
Connecter for a power adapter.
Power Switch.
6
