Site Selection & Preparation
the fireplace insert. Ensure
that all four (4) of the insert's
feet rest securely on this
surface.
Option #1 - The power cord
can be lead from behind the
fireplace trim and along the
wall to an outlet near the
fireplace.
Option #2 - A new outlet can be
installed inside the new frame
construction.
Figure 1
8
3
23 "
8
(594 mm)
Option #3 - The power cord
can be lead from behind the
mantel and along the wall to
an outlet near the fireplace.
Existing Fireplace
Installation
1. Seal all drafts and vents
with non-fibrous insulation
materials to prevent chimney
debris from falling into the
fireplace insert. Do not install
into an existing fireplace
that is prone to leaks or
dampness.
2. Cap the top of the chimney
flue to prevent rain from
entering.
3. Plan your electrical power
supply (refer to noTE 1).
1
11 "
8
(283 mm)
1
22 "
2
(572 mm)
