Site Selection & Preparation
5. Assemble the mantel
surround kit (refer to the
mantel assembly instructions)
or construct the custom
surround with an opening of
24 inches (610 mm) wide X
23 ¼ inches (591 mm) high X
11 ½ inches (292 mm)

Fireplace Installation

1. Make sure the units Main On/
off switch is switched off
(refer to operating instruction
section).
2. Plug the unit into a 15 Amp,
120 volt outlet. If the cord
does not reach, you may use
an extension cord rated for a
minimum of 1875 Watts.
3. Push the fireplace into the
opening being careful not
to damage the base of the
mantel or cabinet so that
the fireplace is flush with the
mantel or cabinet.
4. Level the unit with shims if
necessary (not provided).
10
WARNINg: Do not attempt
to wire your own new outlets
or circuits. To reduce the risk
of fire, electric shock or injury
to persons, always use a
licensed electrician.
deep.
WARNINg: Ensure the
power cord is not installed so
that it is pinched or against a
sharp edge and ensure that
the power cord is stored or
secured to avoid tripping or
snagging to reduce the risk of
fire, electric shock or injury to
persons.
