NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment. WARNING: Procedures and techniques which, if not carefully followed, will expose the user to the risk of fire, serious injury, or death. www.dimplex.com...
It can be reset by switching the 3-Position Switch to Strip Off and waiting five (5) minutes before switching the unit back on. Battery CAUTION: If you need to continuously reset the heater, Cover disconnect power and call Dimplex customer service at 1-888-DIMPLEX (1-888-346-7539).
The surface should be completely dried with a lint free cloth to prevent water spots. To prevent scratching, do not use abrasive cleaners or spray liquids on any surface. www.dimplex.com...
PREPARATION FOR SERVICE Figure 4 CAUTION: If unit was operating prior to servicing allow at least 10 minutes for lights, heating elements and top panel to cool off to avoid accidental burning of skin. Remove the firebox out of the cabinet or wall frame that surrounds the unit.
WARNING: Unplug or disconnect power at the circuit it from below the reflective flame panels on the back. breaker before attempting any maintenance to reduce the Carefully rest it inside on the rear flame panels. risk of electric shock or damage to persons. www.dimplex.com...
NOTE: It is recommended to protect the rear flame WARNING: If the fireplace was operating prior to ser- panels from scratches prior to resting the light housing on vicing allow at least 10 minutes for light bulbs and heating them using cloth or piece of cardboard. elements to cool off to avoid accidental burning of skin.
Feed the new power cord through the junction box and squeeze the new strain relief in place on the cord and junction box. Re-connect wires. –(Wide blade on the plug is the neu- tral side of the power cord). Reassemble in the reverse order as above. www.dimplex.com...
ASSEMBLY PART PICTURES VIEW FROM UPPER LEFT SIDE (WIRE & SWITCH COVER REMOVED) Rear Flame Panel Light Harness Channel Flicker Rod Light Block Light Socket Bracket and Bulbs Heater Assembly and Cover Flicker Rod and Bracket Heat Deflector Grille VIEW FROM BOTTOM RIGHT SIDE (WIRE &...
Page 12
Black wire from Flicker Heating Element Motor and Neutral from Remote Control Receiver REMOTE CONTROL RECEIVER Line - Remote Side of 3-Position Switch Neutral - Connects to Power Cord and Terminal Block Switch Output - Heater On/ Off Switch and Terminal Block www.dimplex.com...
Page 13
HEATER ASSEMBLY VIEW FROM BOTTOM OF ASSEMBLY Connects to Lower Heating Element Connects to Upper Heating Element Heating Element - Connects to Heater/Blower Motor and Terminal Block Heater/Blower Motor Upper Heating Element - Connects to Heater/Blower Motor and From Terminal Block Line In from Cutout and Connection to Upper...
Burnt out light bulbs Replace light bulbs visible Loose wiring Check wiring connections Defective light harness Replace light harness Log set dim, not glowing Burnt out light bulbs Replace light bulbs Flame Shudder Defective Flicker motor Replace Flicker motor www.dimplex.com...
Page 15
PROBLEM CAUSE SOLUTION Heater Heater is not turning off Improper operation Refer to Operation Section Defective Heater On/Off switch Replace Heater On/Off switch Defective Thermostat Replace Thermostat Defective Remote Control Receiver Replace Remote Control Receiver. Initialize to Re- mote Control. Heater is not turning on Improper operation Refer to Operation Section...
