Installation
20.4" (517mm) wide x 21.1"
(536mm) high. (See Figure 2 for
all dimensions)
3. Make sure the unit's
3-Position switch is switched
OFF (refer to operating
instruction section).
4. Plug the unit into a 15 Amp,
120 VAC outlet. If the cord
does not reach, you may use
a No. 14 AWG minimum size
extension cord rated for a
minimum of 1875 Watts.
8
Figure 2
21.1 [537]
22.1 [561]
21.9 [555]
20.4 [517]
9 [229]
21.1 [536]
