Owner's Manual
Model Numbers:
DS4411
DS2205
Serial Number
Model Number
Part Number
Valued Customer,
Thank you and congratulations for purchasing a Dimplex
electric stove. Over the years, valuable memories
will occur around the warmth and comfort of your
stove. Thank you for allowing our product to be the
backdrop for those special
moments.
Quality checked by:
7210170100r00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS4411 and is the answer not in the manual?

Questions and answers

Related Manuals for Dimplex DS4411

Summary of Contents for Dimplex DS4411

  • Page 1 Model Number Part Number Valued Customer, Thank you and congratulations for purchasing a Dimplex electric stove. Over the years, valuable memories will occur around the warmth and comfort of your stove. Thank you for allowing our product to be the backdrop for those special moments.
  • Page 2 4. If you have any technical questions regarding the operation of your Compact Stove, or require service for your stove contact Dimplex North America customer service at 1-888-DIMPLEX (1-888-346-7539).

  • Page 3: Table Of Contents

    CONTENTS PAGE 1 Important Instructions PAGE 3 Model and Serial Number Information PAGE 4 Compact Stove Installation PAGE 4 Operation PAGE 6 Maintenance PAGE 8 Warranty...

  • Page 4: Important Instructions

    IMPORTANT INSTRUCTIONS Please Retain This User’s Guide For Future Reference When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Read all instructions before using the Compact Stove. 2. The heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
  • Page 5 Any other use not recommended by the manufacturer may cause fire, electric shock or injury to persons. 14. To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way. Avoid the use of an extension cord. Extension cords may overheat and cause a risk of fire. If you must use an extension cord, the cord must be No. 14 AWG minimum size and rated no less than 1875 Watts.

  • Page 6: Model And Serial Number Information

    or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and the receiver.

  • Page 7: Compact Stove Installation

    Compact Stove Installation NOTE: A 15 Amp, 120 Volt circuit is required. A dedicated circuit is preferred but not essential in all cases. A dedicated circuit will be required if, after installation, the circuit breaker trips or fuses blow on a regular basis when the heater is operating. Additional appliances on the same circuit may exceed the current rating of the circuit breaker.
  • Page 8 CAUTION: If you need to continuously reset the heater, unplug the unit and call Dimplex North America Limited at 1-888-346-7539. Remote Operation (Figure 3) The stove is supplied with an integrated on/off remote control.

  • Page 9: Maintenance

    to turn the stove off. Figure 3 Remote Control Initialization 1. Place the Main ON/OFF Button Battery Switch (Figure 2A) in the OFF (“ o ”) position. Button 2. Wait a minimum of five (5) seconds and then Battery place the Main ON/OFF Cover Switch in the Remote (right) position.
  • Page 10 the flame or when the clarity and detail of the log exterior disappears. There are two (2) bulbs located under the log set which generate the flames and embers. Helpful Hints It is a good idea to replace all light bulbs at one time if they are close to the end of their rated life. Group replacement will reduce the number of times you need to open the unit to replace light bulbs.

  • Page 11: One Year Limited Warranty

    One Year Limited Warranty Products to which this limited warranty applies This limited warranty applies to the following models of your newly purchased Dimplex electric stove DS4411 and DS2205 and to newly purchased Dimplex stove surrounds (mantels) and trims. This limited warranty applies only to purchases made in any...
  • Page 12 • Dimplex will in its sole discretion either repair or replace such defective product or part without charge. If Dimplex is unable to repair or replace such product or part, or if repair or replacement is not commercially practicable or cannot be timely made, Dimplex may, in lieu of repair or replacement, choose to refund the purchase price for such product or part.
  • Page 13 Dimplex North America Limited 1367 Industrial Road Cambridge ON Canada N1R 7G8 1-888-346-7539 www.dimplex.com © 2009 Dimplex North America Limited Approved for use in the United States and Canada Printed in China...

This manual is also suitable for:

Ds2205
