IMPORTANT SAFETY INFORMATION: Always read this manual first before attempting to service
this stove. For your safety, always comply with all warnings and safety instructions contained in this
manual to prevent personal injury or property damage.
Dimplex North America Limited
1367 Industrial Road Cambridge ON Canada N1R 7G8
1-888-346-7539 www.dimplex.com
In keeping with our policy of continuous product development, we reserve the right to make changes without notice.
© 2012 Dimplex North America Limited
Service Manual
Model Number
DS2205
DS2307
DS3311
DS4411
REV
PCN
DATE
03
-
28-MAR-12
7400570000R03
Advertisement
Table of Contents
Related Manuals for Dimplex DS2205
Summary of Contents for Dimplex DS2205
-
Page 1: Model Number
Dimplex North America Limited 1367 Industrial Road Cambridge ON Canada N1R 7G8 DATE 1-888-346-7539 www.dimplex.com 28-MAR-12 In keeping with our policy of continuous product development, we reserve the right to make changes without notice. © 2012 Dimplex North America Limited 7400570000R03... -
Page 2: Table Of Contents
NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment. WARNINg: Procedures and techniques which, if not carefully followed, will expose the user to the risk of fire, serious injury, or death. www.dimplex.com... -
Page 3: Operation
CAUTION: If you need to continuously reset the The Heater On/Off Switch supplies power to the heater fan heater, unplug the unit and call Dimplex North America and the heater element. When the switch is in the On posi- Limited at 1-800-668-6663. -
Page 4: Maintenance
Light bulb Requirements Quantity of two (2) clear chandelier or candelabra bulbs with an E-12 (small) socket base, 25 Watt rating. bulb Replacement Depending on the unit there are two different types of ac- www.dimplex.com... -
Page 5: Exploded Parts Diagram
ExPLODED PARTS DIAgRAM DS2205 DS2307 DS3311 DS4411 1. Front Foot 0438460160RP 2. Rear Foot 0438460160RP 3. Logset Assembly 0438500100RP then use 0438500400RP 4. Flicker Motor 120V 2000210100RP 5. Heater Assembly (with Cutout) 2200491000RP 6. Capacitor 2300030100RP 7. Heater Switch 2800070200RP 8. -
Page 6: Wiring Diagram
With Integral Remote Control Receiver and Thermostat Lamp Lamp RECEIVER, Switch Switch REMOTE CONTROL Flicker Motor Capacitor Terminal Block Blower Motor Wire of wide blade of plug Wide blade (N) Cord Narrow Blade (L) Cutout Element Thermostat With External Remote Control Receiver and Thermostat www.dimplex.com... - Page 7 With Three Switch Control (No Remote) Lamp Lamp Switch Switch Switch Flicker Motor Terminal Block Capacitor Blower Motor Cutout Element Bank...
-
Page 8: Switch Replacement - Units With Thermostat
Pick up new switch and install wires to terminals on switch – ensure wires are attached to same terminals as prior switch – see Figure 6 for wire colours. Insert switch through location hole and snap in place. Reassemble in the reverse order as above. www.dimplex.com... -
Page 9: Flicker Motor/Flicker Rod Replacement
Flicker Motor/Flicker Rod Replacement WARNINg: Disconnect power before attempting any maintenance to reduce the risk of electric shock or damage WARNINg: If the stove was operating prior to servic- to persons. ing, allow at least 10 minutes for light bulbs and heating elements to cool off to avoid accidental burning of skin. -
Page 10: Troubleshooting Guide
Log set dim, ember bed not Burnt out light bulbs Replace light bulbs glowing Flame Shudder Defective flicker motor Replace flicker motor Light leaking around the log set Log set not positioned properly Check log set for proper fit www.dimplex.com... - Page 11 PROBLEM CAUSE SOLUTION heater Heater is not turning off Improper operation Refer to Operation Section Defective Heater On/Off Switch Replace Heater On/Off Switch Defective Thermostat Replace Thermostat Defective Remote Control Receiver Replace Remote Control Receiver. Initialize to remote control Heater is not turning on Improper operation Refer to Operation Section Defective Heater On/Off Switch...
