KEY LOCK INSTALLATION INSTRUCTIONS
The installation and servicing of the equipment should be done by qualified experienced technicians.
The Key Lock kit prevents tampering of the controls used
to set temperatures and heating or cooling functions.
PERSONAL RISK HAZARD
Underwriter's Laboratories Inc. listed. For institu-
tional use only where supervisory monitoring is
available. Any other use may increase the risk of
personal injury or property damage.
1. Remove front from unit by pulling bottom out
and then lifting upward.
2. Loosen retaining screw by one-turn counter-
clockwise. Disengage door pins from housing
slots and remove door.
3. Insert the key lock assembly in the housing
slots. Tighten retaining screw one-turn clock-
wise. Do not overtighten.
Part No. 11113602
Printed in U.S.A.
CAUTION
Installation Instructions
Due to policy of continual product
improvement, the right is reserved to
change specifications and design
Made in USA
without notice.
Key Lock Assembly
RETAINING
SCREW
P1201702R
May 2003
