StepMill SM916
®
Assembly Manual
001-7199 - -040510B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the StepMill SM916 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stairmaster StepMill SM916

  • Page 1 StepMill SM916 ® Assembly Manual 001-7199 - -040510B...
  • Page 2: Table Of Contents

    Table of Contents Model SM916 Specifications ............................... 2 Safety Warnings ..................................3 Safety Caution and Warning Labels ........................... 4 Before You Start ..................................5 Hardware ....................................6 Box Contents ..................................... 7 Assembly .....................................9 Contact Information ................................15 Product Speci cations Model SM 916 Dimensions: 29"...
  • Page 3: Important Safety Instructions

    Examine this machine for loose parts or signs of wear. Pay special attention to the steps. Contact StairMaster® Customer Service for repair information. Use only genuine StairMaster® replacement parts. Set up and operate your StepMill® on a hard, level surface.
  • Page 4: Safety Caution And Warning Labels

    Safety Caution and Warning Labels Before using your product : Find and read all warning labels located on the StairMaster Commercial Series ® StepM ill SM916, prior to using your product. Be sure to replace any warning label if damaged, illegible, ®...
  • Page 5: Before You Start

    Before You Start SM 916 . Locate the area where you will assemble and use your StairMaster Commercial Series StepMill ® ® We recommend you install it on a hard, level surface. Allow an assembly area of at least 36” (0.91 m) on each side and behind the machine.
  • Page 6: Hardware

    Hardware Hardware Ref # Description 5/16 " - 18 Flat Head Screw 1/4 " - 20 x 1" Button Head Screw 1/4 " - 20 x 3/4" Phillips Head Screw 5/16 ” - 18 Nut 1/4” - Flat Washer 5/16 ” - Flat Washer Hardware not to scale Assembly Manual...
  • Page 7: Box Contents

    Box Contents Box 1 StepMill SM916 ® Assembly Manual StepMill ® SM 9 1 6 Assembly Manual 001-7199 - 052008B 001-7199 - 052008B Ref # Description Assembly Manual Owner’s Manual Kit Rivet Puller Rivet Transport Wheels Cotter Pins Clevis Pins Levelers Power Supply &...
  • Page 8 Box Contents Box 2 Ref # Descritpion Upper Mast Console Bottle Holder Assembly Manual...
  • Page 9: Assembly

    Assembly SM 916 . All instructions The following instructions provide direction to assemble the StairMaster StepMill ® ® in the manual are given with the orientation of standing on a level surface and facing the machine. SM 916 Step 1: Unpacking the StepMill ®...
  • Page 10: Assembly Manual

    Assembly Step 3: Install Levelers and Transport Wheels Parts Hardware Cotter Pins Figure Figure Assembly Manual...
  • Page 11: Ref

    Assembly Step 4: Attach Mast Parts Hardware y. 4 y. 4 y. 4 Figure Step 5: Attach Hand Rails Parts Hardware - 20 x NOTE: Figure Figure Assembly Manual...
  • Page 12 Assembly Step 6: Install Top Cover Parts Completed assembly from Step 5. Ref 17, Top Cover Qty. 1 Hardware Ref 10, Rivet Qty. 8 Tools Ref 9, Rivet Puller 6-1 Remove the top Rivets and upper side Rivets on both left and right side covers to install the Top Cover (Figure 6 A).
  • Page 13 Assembly Step 7: Install Console Parts Completed assembly from Step 6. Ref 19, Console Qty. 1 Hardware Ref 3, 1/4" - 20 x 3/4" Phillips Head Screw Qty. 4 Tools Phillips Head Screwdriver 7-1 Connect the cables from the Mast to the 20 pin connector on the PC board (Figure 7A &...
  • Page 14 Assembly Step 8: Install Cup Holder Parts Completed assembly from Step 7. Ref 20, Bottle Holder Qty. 1 Hardware Ref 2, 1/4” - 20 x 1” Button Head Screw Qty. 3 Ref 5, 1/4” Flat washer Qty. 3 8-1 Attach the Bottle Holder to the Mast with 3 Button Head Screws and 3 Flat washers (Figure 8).
  • Page 15 Assembly Step 10: Connecting Power Supply Parts Ref 15, Power Supply Qty. 1 10-1 Connect the DC Power Cable from the Power Supply to the power connector located on the bottom cover (Figure 10). 10-2 Place the Power Supply on the floor near an AC wall outlet.
  • Page 16: Safety Warnings

    1-888-678-2476 | www.stairmaster.com Please supply the serial number of your machine and the date of purchase when you call StairMaster. Use the space in the boxes below to write down this information. To nd the serial number on your machine, refer to the Safety Warning Label information page.
  • Page 17 © 2010 Core Fitness, LLC, dba StairMaster. All rights reserved. StairMaster and the StairMaster logo are either registered trademarks or trademarks of Core Fitness, LLC. All other trademarks are owned by their respective companies. StairMaster, 8000 NE Parkway Drive, Suite 220, Vancouver, WA 98662 1-888-678-2476 | www.stairmaster.com...
