SC 916 StairClimber
Assembly Manual
001-7201 -040510A

Advertisement

loading
Need help?

Need help?

Do you have a question about the SC916 StairClimber and is the answer not in the manual?

Questions and answers

Related Manuals for Stairmaster SC916 StairClimber

Summary of Contents for Stairmaster SC916 StairClimber

  • Page 1 SC 916 StairClimber Assembly Manual 001-7201 -040510A...

  • Page 2: Table Of Contents

    Table of Contents Model SC916 Specifications ................................2 Important Safety Instructions ................................Safety Warning Labels ................................5 Before You Start ....................................6 Assembly ........................................ 7 Contacts ....................................... 15 Product Speci cations Model SC 916 Speci cations Dimensions: 27” W x 43” L x 68” H (68 cm x 109 cm x 173cm) Unit Weight: 150 lbs (68 kg) Shipping Package Weight: 178 lbs (81 kg) Workout Area: 50”...

  • Page 3: Important Safety Instructions

    Contact your doctor before using the machine again. Examine this machine for loose parts or signs of wear. Pay special attention to the pedals. Contact Customer Service for repair information. Use only genuine StairMaster® replacement parts. Set up and operate your StairClimber on a hard, level surface.
  • Page 4 5/16” - Flat Washer 5/16 ” - Split Lock Washer 1/4” - Flat Washer 1/4” - Split Lock Washer Hardware not to scale Box 1 Contents SC916 StairClimber Assembly Manual 9 1 6 StairClimber Assembly Manual 001-7201 - 090409B 001-7201 - 090409B...

  • Page 5: Safety Warning Labels

    Safety Warning Labels Before using your product : Find and read all warning labels before using your product. Replace any warning label if damaged, illegible, or missing. If you need replacement labels, please call a StairMaster ® representative at 1-888-678-2476.

  • Page 6: Before You Start

    Before You Start Commercial Series SC 916 StairClimber. Locate the area where you will assemble and use your StairMaster ® We recommend you install it on a hard, level surface. Allow an assembly area of at least 36” (0.91 m) on each side and behind the machine.

  • Page 7: Assembly

    Assembly Step 1: Removing Box Tools Box knife or Strap Cutters Claw hammer 1-1 Use the box knife to cut and remove the plastic banding straps from around the pallet and carton (see Figure 1) . Use extreme Caution when using shears or a razor knife.
  • Page 8 Assembly Step 3: Removing Console/Upper Mast Tools Box knife 3-1 Using the box knife, open the top of the box holding the Console/Upper mast weldment (see Figure 4). 3-2 Bend the box center flap inward. Remove Box 1 and place to the side. 3-3 Carefully lift the console/upper mast weldment out of the box and place to the side (see Figure 5).
  • Page 9 Assembly Step 4: Removing the Main SC 916 Body 4-1 Pull the lower body of the SC916 forward, and with the assistance of another person lift the machine o the shipping pallet and on to the floor (see Figure 6). Step 5: Removing Covers Tools Phillips screwdriver...
  • Page 10 Assembly Step 6: Removing Console Tools Phillips screwdriver 6-1 Remove the 4 Phillips screws attaching the SC916 Console to the upper mast weldment previously placed to the side in Step 3 (see Figures 9 and 10 ). 6-2 Remove CHR and J6 Polar HR cables from the back of the console connected to the PC board (see Figure 11).
  • Page 11 Step 7: Routing Main Cables 7-1 Route the Main cable and the TV cable located at the top of the lower mast through the bottom of the Top of Upper Mast upper mast weldment and exit out the console plate (see Figure 12).
  • Page 12 Assembly Step 9: Attaching handrails Tools 5/32" or 4mm T-handle Hardware Ref 2: 1/4” - 20 x 1/2” Button Head Screw, Qty 2 Ref 3: 1/4”- 20 x 1-1/4” Hex Head Screw, Qty 4 Ref 7: 1/4”- Flat Washer, Qty 4 Figure 15 Ref 8: 1/4”- Lock Washer, Qty 4 NOTE: This Step requires 2 people to complete Steps...
  • Page 13 Assembly Step 10: Replacing the Leg Levelers 10-1 Replace the 2 leg levelers previously removed in Step 9 (see Figure 19). 10-2 Return the SC 916 to its upright position. Step 11: Attaching the Console Tools Figure 19 Phillips screwdriver 11-1 Grasp the SC 916 console and connect the CHR cable from the upper mast weldment to P3 on the PC board (see Figure 20).
  • Page 14 Assembly Step 13: Final Check Failure to visually check and test assembly before use can cause damage to the equipment. It can also cause serious injury to users and bystanders. 13-1 Tighten all hardware. 13-2 Read all warnings on machine. Refer to the Owner’s Manual for: Operating Instructions Maintenance Instructions...

  • Page 15: Contacts

    Vancouver, Washington, 98662 Tel: 1-888-678-2476 Fax: 1-360-314-2865 Please supply the serial number of your machine and the date of purchase when you call StairMaster. To nd the serial number on your machine, refer to the Safety Warning Label information page. Serial Number...
