- Page 1 CILT13D1G (DC AI 2.8~12mm) CILT13D7G (3.6mm) 620Line Intense Light Tamperproof Dome Vandal Resistant w/Chameleon Cover Wall/Ceiling Mount Please read this manual thoroughly before operation and keep it handy for further reference.
-
Page 2: Warning And Caution
WARNING & CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK D O N O T R E M O V E C O V E R ( O R B A C K ) . N O U S E R S E R V I C E A B L E P A R T S I N S I D E R E F E R S E R V I C I N G T O Q U A L I F I E D... -
Page 3: Package Contents
PACKAGE CONTENTS make Please sure that the following items are included in the Package: 3 Mounting Screws and Anchors 1 Tamperproof Screw 1 Wrench 1 Video Test Connector 1 Power Cable 1 Chameleon Cover... -
Page 4: Camera Installation
CAMERA INSTALLATION CHAMELEON COVER Place the Chameleon Dome over the camera and push until it snaps into position. ● Notes : Optional painting before installation * Painting method for the Chameleon Dome * Spray the color of your choice onto the Chameleon cover * If necessary, apply a second coat... - Page 5 FEATURES 1. SUPER HIGH RESOLUTION Sony Super HAD II CCD with an innovated new DSP Technology will enable to achieve Super High Resolution 620TVL with High S/N Ratio. 2. SENS-UP Digitally manipulates the exposure level of the image to produce bright images in the darkest of scenarios.
-
Page 6: Osd Menu Tree
OSD MENU TREE EXPOSURE • 3D-DNR • RETURN • SENS-UP • BACKLIGHT • AGC • LENS • BLC • HLC • D-WDR WHITE BALANCE • AWB MODE • R-Y GAIN • B-Y GAIN • RETURN • ATW • MANUAL • PUSH •... -
Page 7: Osd Menu Details
OSD MENU DETAILS *EXPOSURE* 1) LENS DC IRIS : Used with DC auto iris lens. - BRIGHTNESS : Adjusts image brightness. (000 ~ 100) - E. SHUTTER : Auto / Manual Shutter can be selectable. MANUAL : Used with manual lens. - BRIGHTNESS : Adjusts image brightness. -
Page 8: White Balance
OSD MENU DETAILS *WHITE BALANCE* 1) AWB MODE ATW : Automatically white balances the image. MANUAL : Select M-WR or M-WB then enter the MANUAL white balancing mode to manually adjust the scene to your desired settings. 2) R-Y GAIN : Adjusts the red gain level. (000 ~ 255) 3) B-Y GAIN : Adjusts the blue gain level. - Page 9 OSD MENU DETAILS *MOTION* 1)MOTION : Adjust motion detection settings. 2)AREA : Selects the current motion zone from area1 to 4 3)SENSITIVITY : Sets the desired multiple of the digital exposure length. (000~030) 4)DISPLAY : Sets the desired display mode when the motion is detected. (OFF/MESSAGE/TRACE) 5)HOLD TIME : Sets the hold time when the event is detected.(000~015) 6)ALARM OUTPUT : Selects the alarm output mode.
- Page 10 OSD MENU DETAILS *EXIT* SAVE & EXIT : Press to save the current settings and exit main menu. EXIT : Press to exit main menu without saving settings.
-
Page 11: Specifications
410,000 pixels Image Sensor 811(H) x 508(V) , 1/3” CCD Total Pixels 768(H) x 494(V) , 1/3” CCD Effective Pixels CILT13D1G : DC AUTO IRIS 2.8~12mm Lens Type CILT13D7G : 3.6mm Maximum Aperture Ratio 1 : 1.3 ~2.0 Scanning System... - Page 12 DIMENSIONS * TOP VIEW * SIDE VIEW HIGH IMPACT DOME...
-
Page 13: Warranty
WARRANTY... - Page 14 MEMO...
- Page 15 MEMO...
- Page 16 200 New Highway Amityville, NY 11701 631-957-8700 www.specotech.com Rev. 120719 Speco Technologies is constantly developing product improvements. We reserve the right to modify product design and specifications without notice and without incurring any obligation.
