3 General Presentation
3.1 Description
The Fastrack M1306B description is given in the Figure 4 below.
Micro-Fit
connector
Figure 4: Fastrack M1306B general description
confidential ©
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement.
WM_PRJ_M13_UGD_001 -003
Front cap
BACK CAP
LED
Fastrack M1306B User Guide
General Presentation
Sub HD
connector
SMA
connector
Back cap
Extractible
SIM card
holder
SIM card
holder ejector
November 11, 2006
Page: 19 / 65
