3 Recommended Interface Circuitry

Abbreviations:
VCC - Represents the logic supply voltage used by the application.
VREF_CA- Current amplified reference voltage used for all logic interface circuitry to the CM52.
Component proposals:
Transistors not showing a base resistor should be interpreted as a BRT (Built in Resistor
Transistor) i.e. Toshiba RN1308.
The inverting buffers should preferably be Schmitt-Triggered, i.e. Toshiba TC7S14 or similar.
3.1

Status Group Recommended Circuitry

The status group contains four signals, one output signal from the application and three input
signals to the application.
