System Connector Interface Pinout

2.3.2
Pin Signal
1 Reserved
2 VREF
3 Reserved
4 VRTC
5 GND
6 GND
7 AFMS
8 GND
9 AGND
10 ATMS
11 Reserved
12 MODULE_PWR_EN_B
13 Reserved
14 Reserved
15 HW_SD
16 Reserved
17 PCMCLK
18 PCMSYNC
19 PCMULD
20 PCMDLD
21 GND
22 GND
23 DCD / VPPFLASH
24 Reserved
1
Default function if GPS option on board
2
Default function if RTC option on board
CM52 Integrators' Manual
WI_DEV_CM52_UGD_001-001
Page 19 of 53
Description
Logic Voltage
2
Supply pin for RTC
Chassis Ground
Chassis Ground
Analog Audio from Wireless CPU
Chassis Ground
Analog Reference
®
Analog Audio to Wireless CPU
®
Switches the Wireless CPU on/off
(hardware-wise), active low
Hardware shutdown
PCM Clock output
PCM Frame sync
PCM Voice input to Wireless CPU
PCM Voice output from Wireless CPU
Chassis Ground
Chassis Ground
Data Carrier Detect & Flash programming
voltage input
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement.
Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable
Dir Pin Type
O Reference
I Power
Ground
Ground
®
O Audio
Ground
Audio
I Audio
I
I/O
O CMOS
O CMOS
®
I CMOS
®
O CMOS
Ground
Ground
O / I CMOS /
Power
O
CM52 Integrators' Manual
Alternate Dir Pin
Function Type
1
TIMEMARK O CMOS
1
GPS Fix O CMOS
1
GPS VRTC I Supply
1
UART3_RX I CMOS
1
UART3_TX O CMOS
RINGER O CMOS
