2 Integrating the CM52 Wireless CPU

2.1

Overview

The CM52 is a dual band, dual mode CDMA transceiver Wireless CPU
band for CDMA and AMPS and in the 1900 MHz band for CDMA. It is designed for consumer and
OEM industrial voice and data applications.
The CM52 Wireless CPU
provide wireless communication capability for the product. The target chassis could be in a wide
variety of forms such as a residential electric meter, a point of sale terminal, an alarm panel, or an
automobile console. All initial configuration, mode control, and operational commands are issued
to the Wireless CPU
CPU circuitry has been designed to meet the environmental requirements of a large range of
®
commercial and industrial users.
2.2

Mechanical Description

The CM52 has no mechanical elements other than the main PCB assembly. All critical electronic
components are shielded using six cans to prevent internal and external electromagnetic
interference from degrading the Wireless CPU performance and to prevent the Wireless CPU
interfering with other nearby devices. The Wireless CPU
connector and secured with four screws.
The antenna interface is provided via a board mounted RF connector at the opposite end of the
board from the system connector. See Section 2.8 for more information on antenna connector
options.
The Wireless CPU
show 3-D models of the Wireless CPU

Mechanical Dimensions

2.2.1
The following figures provide the mechanical dimensions for several CM52 variants (CM52002,
CM52003, and CM52004). There is also a drawing detailing the mechanical keep-out regions.
CM52 Integrators' Manual
WI_DEV_CM52_UGD_001-001
Page 11 of 53
is intended for mounting into an application developer's chassis to
®
over an RS-232 serial port using a flexible AT command format. The Wireless
®
has no keypad, display, microphone, speaker, or battery. The following figures
®
Figure 1: CM52 Primary Side
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement.
Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable
®
is plugged into the fixed mating
®
.
®
Figure 2: CM52 Secondary Side
CM52 Integrators' Manual
. It operates in the 800 MHz
®
from
®
