You can clear CMOS t
o restore system default setting. To clear the
1.
Turn off the system and unplug the AC power.
2.
Remove ATX power cable from connector PWR2.
3.
Locate JP14 and short pins 2-3 for a few seconds.
4.
Return JP14 to its normal setting by shorting pin 1 & pin2.
5.
Connect ATX power cable back to connector PWR2.
Pin 1
S
D
a
t
a
S
D
a
t
a
1
1
Normal Operat
ion
Clear CMOS
(default)
CMOS, follow the procedure below.
Tip: When should I Clear CMOS?
1. Boot fail because of overclocking...
2. Forget password...
3. Troubleshooting...
