Bar Views - Vertical And Horizontal - Altigen MaxInSight Manual

From and To fields (24-hour clock). Be sure the time you select in the
From field precedes the time you select in the To field.
7. Select a time interval: 15 minutes, 30 minutes, or one hour.
8. Click OK. A time line view is displayed. The workgroup number(s)
and display colors are shown at the top.
Figure 4. Time Line View showing number of incalls every 15 minutes for the last
hour

Bar Views - Vertical and Horizontal

You can display one selected field of multiple workgroups in a bar view
that shows either historical data or real time data.
1. Choose either Add > Add Vertical Bar View or Add > Add
Horizontal Bar View. The following dialog box appears.
20 MaxInSight Manual
