Chapter 3
Troubleshooting
This chapter discusses testing AT-MR415T/AT-MR815T Micro Repeaters for a
valid connection as well as steps to detect other problems.
Performing a Connection Test
In order to test for a valid connection, as well as confirm the correct operation
of the network, follow the steps outlined below. Refer to Figure 11.
1. Connect port 1 and port 2 of a single AT-MR415T/AT-MR815T Micro
Repeater to two computers and turn on the HUB power supply by
connecting the AC adapter. (In Figure 11 above, PC B is connected to port 1
and PC A is connected to port 2.)
2. Check to make sure the LINK ON lamps of both port 1 and port 2 are
lighted.
3. Using your own software, confirm proper communication between
machines by sending data from the computer connected to port 1 to the
computer connected to port 2. (For example, if you have installed the
CentreNET PC/TCP protocol, use the "PING" command.)
PC B
PC A
Figure 11: AT-MR815T Connection Test
PC C
19
