Installation
Table 1 shows the model variations and different power arrangements for
AT-MR415T/AT-MR815T Micro Repeaters:
Model
AT-MR415T-10
AT-MR815T-10
AT-MR415T-20
AT-MR815T-20
AT-MR415T-30
AT-MR815T-30

UTP (RJ-45) Connectivity

A UTP cable with RJ-45 connectors is shown in Figure 5. For a 10Base-T link
between a repeater and a Medium Attachment Unit (MAU) or Network
Interface Controller (NIC), the cable is wired straight through.
10Base-T UTP cables can be up to 100 meters (328 ft.) in length. The cable
should be 22 to 26 AWG UTP wire with 100
AT-MR815T Micro Repeater uses RJ-45 modular connectors for 10Base-T
connections.
Do not connect standard telephone line into a signal connector.
10
Table 1: Model Configurations
Location
North America
North America
Europe/Asia
Europe/Asia
United Kingdom
United Kingdom
Figure 5: RJ-45 Connector
Note
Voltage
90/120 VAC
90/120 VAC
200/240 VAC
200/240 VAC
200/240 VAC
200/240 VAC
impedance. The AT-MR415T/
