Page 2
Dear Sir, Madam, Congratulations on the purchase of your airconditioner. You have acquired a high quality product that, if used responsibly, will give you many years of pleasure. Please read these instructions for use first in order to ensure the maximum life span of your airconditioner. On behalf of the manufacturer, we provide a 24-month guarantee on all material and production defects.
Page 3
C O N T E N T S Safety instructions Parts and functions Before operation Instructions for use Air filter Cleaning Trouble shooting Guarantee conditions Technical data...
SAFETY INSTRUCTIONS Install the device only when it complies with local regulations, by-laws and standards. The unit is only sui- table for use in dry locations, indoors. Check the mains voltage and frequency. This unit is only suitable for earthed sockets, connection voltage 220 - 240 V. / 50 Hz. ...
PA RTS AND FUNCTIONS Outdoor unit Pipe and connecting cable Air inlet Drain hose Air outlet * Warm air comes out when cooling, Earthing terminal cool air comes out when heating. Indoor unit Inlet grill Active carbon filter Screen filter Outlet ** Enzyme filter ** The air flow direction can be...
AT T E N T I O N ! • Because of Auto Recovery Function, if shutting off the power supply during operation, the unit may restart irrespective your intention when turning on the power supply again. • If the unit is not to be used for a long time, shut off the power supply after terminating all operation with remote controller.
Page 7
• Using the unit without the activated carbon filter and/or enzyme filter will not damage your airconditioner. In that case, airborne micro-organisms are not neutralised and unpleasant odours are not removed. • Only use suitable Zibro filters. This will prevent damage to your airconditioner. • Suitable filter packages are available at your dealer.
a. Open the front panel by pulling upward b. Remove the screen filters carefully. Push up the center tab of each screen filter slightly until it is released from the stopper, and remove the filters. Air filters Enzyme filter c. Attach active carbon and enzyme filter in the filterholder on each side of the air conditioner.
Press the ON/OFF button Set the operation mode, circulating , by pressing the operation mode but- ton. Adjust the setting temperature by pressing the temperature setting buttons. Circulating Operation begins after the room temperature reaches the tem- perature set by the remote controller. Adjust the fan speed by pressing the fan speed button.
N O T E ! • If the unit operates in cooling or dry for a long time in high humidity (i.e., windows and doors are opened), dew and water drops may form on the indoor unit. Be aware that falling drops of water can damage your floor (e.g.
Negative ion operation This function is available only when the air conditioner is operating. Press the ON/OFF button Press the ionizer button To stop negative ion operation, press the ionizer button. Air flow adjustment Horizontal adjustment When the ON/OFF button is pressed, the horizontal louver will move automatically. During cooling, During circulation, dry operation...
N O T E ! • When the operation is off, the horizontal louver closes the outlet automatically. • Do not move the horizontal louver by hands. It may make the louver not to work correctly. In order to move the vertical louver, use wireless remote controller without fail. In case the louver does not work correctly, once stop the operation and turn on again.
Page 13
Cancelling “ON Timer” Press the Timer fixing button “ON”. The timer lamp of the indoor unit goes off. “OFF Timer” Example: Set the “Off Timer” to 10 p.m. Operation starts at the set time. Programming the “OFF Time” Press the “TIME ADJ” 3 times. Adjust the time with the button.
“SLEEP Timer” Pressing this button starts the timer mode that will stop the operation after the setting time. Press the “SLEEP” button during the operation. The setting time repeats the following mode by pressing the button: Continuous operation (Sleep Operation: OFF). The operation stops after passing the setting time.
Page 15
Test operation • Same switch as used in Emergency operation. • Test operation is needed in special occasion when you need to test the “cooling operation” even with the room temperature below 16°C, therefore it is not for the normal operation at all. •...
C L E A N I N G Cleaning the front panel Switch the machine off and remove the plug from the socket. Hold the front panel at position “a” and pull it upwards. Clean with a soft dry cloth. Use lukewarm water (max. 30° C) to remove stub- born dirt.
Pick up dust on/around the negative ion generator. Gently rub the tip of the metal needle, in the negative ion generator, with a plastic (tooth-)brush. Do not use a cotton swab or other fluffy object. Close carefully the horizontal louver. Plug in the power plug. The air condi- tioner can be used again.
Damage caused by not using suitable Zibro filters is not covered by the guarantee. Refrigerant loss and/or leakage because of incompetent (dis)connecting the units is not covered by the guarantee conditions applicable to this product.
