- Page 1 P 328 - P 332 GEBRAUCHSANWEISUNG BRUGSANVISNING INSTRUCCIONES DE USO MANUEL D'UTILISATION KÄYTTÖOHJE OPERATING MANUAL...
- Page 2 ALLGEMEINE SICHERHEIT Aus Sicherheitsgründen bitten wir Sie, die Bedienungsanleitung vor Inbetriebnahme sorgfältig zu lesen! Personen, die mit der Bedienungsanleitung nicht vertraut sind, dürfen das Gerät nicht bedienen. A. Kein beschädigtes Kabel verwenden. G. Nicht in Wasser eintauchen. B. Kabel nicht zusammendrücken oder knicken. H.
- Page 3 SICUREZZA > Per motivi di sicurezza, si raccomanda di leggere attentamente il manuale prima di utilizzare l’apparecchio. Le persone che non conoscono il funzionamento del climatizzatore non devono usarlo. Si raccomanda di riporre il manuale in un luogo sicuro per future referenze. A.
- Page 4 IMPORTANT COMPONENTS Control panel Air outlet Handle Casters Filter set Air inlet / filter holder Exhaust air outlet Rubber plug Hose adapter HAF Filter Exhaust hose Active Carbon Filter Window air outlet Remote control Power cord 1. READ THE DIRECTIONS FOR USE FIRST. 2.
- Page 5 Dear Sir, Madam, Congratulations on the purchase of your Zibro air conditioner. This air conditioner has three functions in addition to cooling the air, namely, air dehumidification, circulation and filtration. The mobile air conditioner is extremely easy to operate and move. You have acquired a high quality product that will provide you with many years of pleasure, on condition that you use it responsibly.
-
Page 6: A Safety Instructions
SAFETY INSTRUCTIONS Install the device only when it complies with local regulations, by-laws and standards. The unit is only suitable for use in dry locations, indoors. Check the mains voltage and frequency. This unit is only suitable for earthed sockets, connection voltage 220-240 V. -
Page 7: Installation
ATTENTION! • Never use the device with a damaged power cord, plug, cabinet or control panel. Never trap the power cord or allow it to come into contact with sharp edges. • Never seal the room - where this device will be used - completely airtight. -
Page 8: Operation
IMPORTANT The flexible exhaust hose should be less than 1m during operation, which provides the best performance. This length has been designed especially according to the specifications of the air conditioner. Do not use an extension or exchange for a different hose as that may lead to malfunctioning. - Page 9 DEHUMIDIFYING When the unit is primarily used as a dehumidifier, then please follow these instructions: Do not connect the air exhaust hose and let the warm air go back into the room. You must connect a drain tube to the water outlet (refer to Chapter G).
- Page 10 REMOTE CONTROL LCD Screen Power on/off button Timer and thermostat setting buttons Mode button (select A/C, Fan or Dehumidifier) A/C Fan Speed button (High, Medium, Low) Timer ON / OFF button Celsius / Fahrenheit selector The remote control works in combination with the control panel. Aim the front end of the remote control at the air outlet.
-
Page 11: Air Filter
AIR FILTER The P 328 and P 332 air conditioners are equipped with a 3-layer filter package to clean the circulated room air. The filters are delivered with a separately packed HAF filter and an active carbon filter. These filters must be placed according to instructions before operating the air conditioners. -
Page 12: Continuous Drainage
AIR FLOW Move the air vent directly to adjust the air flow direction. EMPTY INTERNAL WATER CONTAINER Under extreme (environmental) circumstances it may be necessary to empty the internal water container regularly. When the internal water container is full the light will flash and the unit will beep continously. - Page 13 CLEANING WARNING! Switch off the unit and remove the plug from the mains before cleaning the appliance or filter, or before replacing the filters. Clean the housing with a soft, damp cloth. Never use aggressive chemicals, petrol, detergents or other cleansing solutions. For maintenance of the filters, refer to Chapter D “Air Filter”.
-
Page 14: Jtrouble Shooting
TROUBLE SHOOTING Problem Cause Solution Connect to a functioning outlet No power supply and switch on The unit does not function Empty the internal water Water tank indicator is on container (refer to Chapter F) In direct sunlight Close curtains Windows or doors open, many Close doors and windows, or people or heat source in room... -
Page 15: Ltechnical Data
Damage caused by not using suitable Zibro filters is not covered by the guar- antee. To prevent unnecessary expense, we recommend that you always first carefully consult the instructions for use. Take the air conditioner to your dealer for repairs if these instructions do not provide a solution. - Page 16 +44 1606 837787 tel: +43 7434 44867 fax: +44 1606 837757 fax: +43 7434 44868 email: sales@scottmail.co.uk email: pvgaustria@zibro.com > ITALIA e BELGIË PVG Italy SRL PVG Belgium NV/SA Via Niccolò Copernico 5 Industrielaan 55 50051 CASTELFIORENTINO (FI) 2900 SCHOTEN tel:...
