ACV HR FB 300 Product Description & Features

Solar / Multi-Energy Tanks
HR FB / ACCU
HR FB
ACCU

Product Description

• Multi-Energy floor standing Tank-in-Tank hot water tanks
• Ideal as a thermal store for solar collectors, heat pumps, heat recovery from refrigeration
plant and many other energy sources
• Stainless steel construction - no need for sacrificial anodes
• Fully insulated with rigid polyurethane (HR FB) or mineral wool (Accu Tank)
• Includes control panel with thermostat and thermometer
• Optional high recovery copper coil heat exchanger
• Immersion heater connection
• Vented or unvented use, with mains pressure SystemPak available
• HR FB available in two slimline models of 360 and 450 litres with factory fitted casing
• Accu Tank available in two models of 618 and 809 litres, with casing supplied separately
13 11 to enable the tank to pass through standard 800mm doorways
6 7
1
4
2 11
3
12
5
9
10
HR FB
1. Stainless steel inner tank
2. Steel outer tank
3. Insulation :
- Rigid polyurethane foam (HR FB)
- Mineral wool (Accu Tank)
4. Primary water flow
connection
5. Primary water return
connection
6. Domestic cold water inlet
7. Domestic hot water outlet
8. Drain connection
9. Immersion heater connection
6 15 7
1
4
9
13
2
5
3 8
9
14
10
8
ACCU
10. Coil heat exchanger
11. Secondary thermostat pocket
12. Primary thermostat pocket
13. Auxiliary primary water flow
connection for alternative heating
source (Accu Tank only)
14. Auxiliary primary water return
connection for alternative heating
source (Accu Tank only)
15. DHW recirculation or
temperature and pressure relief
valve connection (Accu Tank only)
