Wheelock Series RSS Specification

FIRE ALARM SYSTEMS
DESCRIPTION
Wheelock's patented Series RSS Strobe Appliances and
Series RSSP Strobe Plates have lower current draw while
maintaining outstanding performance, reliability and cost
effectiveness. These versatile appliances will satisfy
virtually all requirements for indoor, wall or ceiling mount
applications.
Strobe options for wall mount models include Wheelock's
patented Multi-Candela strobe with field selectable candela
settings of: 15, 30, 75 or 110cd. Ceiling mount models
are available in 15, 30, 75 or 100cd intensities.
All models may be synchronized when used in conjunction
with the Wheelock SM or DSM Sync Module(s).
Synchronized strobes can eliminate possible restrictions
on the number of strobes in the field of view. Wheelock's
synchronized strobes offer an easy way to comply with
recommendations concerning photosensitive epilepsy.
Wheelock's Series RSS Strobes employ a Patented
Integral Strobe Mounting Plate that can be mounted to a
single gang, double gang, 4" square, 100mm European
backboxes or the SHBB surface backbox. If the flush
backbox has side or top space between it and the finished
wall, the NATP (Notification Appliance Trimplate) may be
used. It provides an additional .65" of trim for the Appliance.
An attractive cover plate is provided for a clean, finished
appearance on all models.
The Series RSSP Multi-Candela Strobe Plates are a cost
effective way to retrofit required strobe appliances to bells,
horns, chimes, multitones or speakers and easily mounts
to standard 4" backboxes or for surface mount use with
Wheelock's SBL2 surface backbox.
For Weatherproof Strobe See Datatsheet
S9004C for RSSWP-2475W-FR.
Copyright 2005 Wheelock, Inc. All rights reserved.
Helping People Take Action
SERIES RSS & RSSP SINGLE
& MULTI-CANDELA STROBES
& STROBE PLATES
Series RSSP
Series RSS
Multi-Candela Indicator
(bottom of Strobe Lens)
Features
• Approvals include: CAN/ULC-S5206-02 for Visual
Signaling Appliances. FCC Part 15 Class B
• ADA/NFPA/ANSI compliant
• Meets OSHA 29 Part 1910.165
• Wall mount models are available with Field
Selectable Candela Settings of 15, 30, 75 or
110 cd. (Multi-Candela models)
• Ceiling mount models are available in 15, 30,
75 or 95cd
• Low current draw with temperature compensation
to reduce power consumption and wiring costs.
• Strobes produce 1 flash per second over the
regulated voltage range
• 12 and 24 VDC models with wide ULC Listed Voltage
using filtered DC or unfiltered VRMS input voltage
• Wall Mount or Ceiling Mount models
• Synchronize with Wheelock SM or DSM sync
module(s)
• ZERO Inrush above Peak
• Compatible with all Wheelock 2-Wire products
• Fast installation with IN/OUT screw terminals
using #12 to #18 AWG wire
